Goodrive270 series VFD for fan and pump
P95 group––Segmented water pressure (available at use of LCD keypad)
Function
Name
code
P95.00 Actual time
Number of pressure
P95.01
segments
P95.02 Start time of T1
P95.03 Pressure at T1
P95.04 Start time of T2
P95.05 Pressure at T2
P95.06 Start time of T3
P95.07 Pressure at T3
P95.08 Start time of T4
P95.09 Pressure at T4
P95.10 Start time of T5
P95.11 Pressure at T5
P95.12 Start time of T6
P95.13 Pressure at T6
P95.14 Start time of T7
P95.15 Pressure at T7
P95.16 Start time of T8
P95.17 Pressure at T8
P96 group––HVAC protection
Function
Name
code
Action upon water
P96.00
pipe break
Detection level of
P96.01
water pipe break
Detection time of
P96.02
water pipe break
Water pipe soft
P96.03
padding function
Description
00.00–23.59
Set the clock date and time in group P92.
0–8
The value 0 indicates this function is disabled.
After Tx elapsed, the water pressure changes to
that corresponding to Tx.
The water pressure before T1 is set to 0.
You need to set the end time segment.
P95.01 indicates the number of valid segments.
The setting that is out of the segment range is
invalid.
If the start time of Tx is later than the start time of
T(x+1), T(x+1) automatically changes to Tx.
Description
0: Normal running
1: Stop
After water pipe break, the VFD running
frequency boosts up to the upper limit or the PID
output upper limit frequency. When it is set to 0,
the water pipe break function is invalid.
Range: 0.0–100.0%
Used to check the detection time of water pipe
break.
Range: 0.0–6000.0s
0: Disable
1: Enable
-262-
Function parameter list
Default Modify
●
00.00
○
0
○
00.00
○
0.0%
○
23.00
○
0.0%
○
23.00
○
0.0%
○
23.00
○
0.0%
○
23.00
○
0.0%
○
23.00
○
0.0%
○
23.00
○
0.0%
○
23.59
○
0.0%
Default Modify
○
0
○
10.0%
○
120.0s
○
0
