P08 group––Enhanced functions
Function
Name
code
P08.00 ACC time 2
P08.01 DEC time 2
P08.02 ACC time 3
P08.03 DEC time 3
P08.04 ACC time 4
P08.05 DEC time 4
Running frequency
P08.06
of jog
ACC time for
P08.07
jogging
DEC time for
P08.08
jogging
P08.09 Jump frequency 1 When the set frequency is within the range of
Jump frequency
P08.10
amplitude 1
P08.11 Jump frequency 2
Jump frequency
P08.12
amplitude 2
P08.13 Jump frequency 3
Description
0x0000–0xFFFF
Description
For details, see P00.11 and P00.12.
The VFD has four groups of ACC/DEC time,
which can be selected by P05. The factory
default ACC/DEC time of the VFD is the first
group.
Setting range: 0.0–3600.0s
The function code is used to define the
reference frequency during jogging.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
ACC time for jogging means the time needed for
the VFD to accelerate from 0Hz to the max.
output frequency (P00.03).
DEC time for jogging means the time needed for
the VFD to decelerate from the max. output
frequency (P00.03) to 0Hz.
Setting range: 0.0–3600.0s
jump frequency, the VFD runs at the boundary
of jump frequency.
The VFD can avoid mechanical resonance
points by setting jump frequencies. The VFD
supports the setting of three jump frequencies. If
the jump frequency points are set to 0, this
-199-
Function parameter list
Default Modify
●
0x0000
Default Modify
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
○
5.00Hz
Depends
○
on model
Depends
○
on model
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.00Hz
○
0.00Hz
