Goodrive270 series VFD for fan and pump
VFD model
GD270-090-4(-L1)(-C3)
GD270-110-4(-L1)(-C3)
GD270-132-4(-L1)(-C3)
GD270-160-4(-L1)
GD270-185-4(-L1)
GD270-200-4(-L1)
GD270-220-4(-Ln)
GD270-250-4(-Ln)
GD270-280-4(-Ln)
GD270-315-4(-Ln)
GD270-355-4(-Ln)
GD270-400-4-Ln
GD270-450-4-Ln
GD270-500-4-Ln
Note:
 The accessory specifications described in the preceding table are ideal values. You can select
accessories based on the actual market conditions, but try not to use those with lower values.
 n = 1 or 3
D.6 Reactors
When the distance between the VFD and the motor is too long, the large parasitic capacitance to
ground produces high harmonic current, which causes the VFD to frequently enable overcurrent
protection and even causes motor insulation damage.
You must configure the output reactor nearby the VFD when the cable length is equal to or greater
than the values in the following table.
Table D-4 Min. non-shield cable length for output reactor configuration
VFD power
1.5–5.5kW
7.5–45kW
55–500kW
Note:

When one VFD drives multiple motors at the same time, you are advised to take the sum of
cable lengths of all motors as the total motor cable length.
Breaker rated
current (A)
250
315
400
500
500
630
630
700
800
1000
1000
1000
1250
1250
Rated voltage (V)
380–480
380–480
380–480
-352-
Optional peripheral accessories
Fast-acting
Contactor rated current
fuse rated
current (A)
300
350
400
500
600
600
700
800
1000
1000
1000
1200
1200
1400
Min. motor cable length (m)
(A)
225
265
330
400
400
500
500
630
630
800
800
1000
1000
1000
50
100
150
