Goodrive270 series VFD for fan and pump
Function
Name
code
Current-loop
P03.09 proportional
coefficient P
Current-loop
P03.10
integral coefficient I
Torque setting
P03.11
method
Torque set through
P03.12
keypad
Torque reference
P03.13
filter time
Setting source of
forward rotation
P03.14 upper-limit
frequency in torque
control
Description
Note:

The two function codes impact the dynamic
response speed and control accuracy of the
system. Generally, you do not need to
modify the two function codes.

Applicable to SVC mode 0 (P00.00=0).

The values of the two function codes are
updated automatically after SM parameter
autotuning is completed.
Setting range: 0–65535
0–1: Keypad (P03.12)
2: AI1 (100% corresponding to triple the motor
rated current)
3: AI2
4: AI3 (same as the above)
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen communication
9: Ethernet communication
10: Reserved
11: PROFINET communication
12–17: Reserved
18: Keypad (for small power models)
-300.0%–300.0% (of the motor rated current)
0.000–10.000s
0: Keypad (P03.16)
1: AI1 (100% corresponding to the max.
frequency)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA (same as the above)
5: Multi-step setting (same as the above)
6: Modbus communication (same as the above)
7: PROFIBUS/CANopen communication (same
as the above)
-166-
Function parameter list
Default Modify
○
1000
○
1000
○
0
○
20.0%
○
0.010s
○
0
