CHAPTER 3 Settings and Measurement
Digital display of measured value
• During Free running/Capturing
RANGE/SPAN mode
display
RANGE/SPAN mode
display
XY-CH number
RANGE/SPAN mode display
X(Y)-axis CH number
X(Y)-axis CH annotation
X(Y)-axis measured value
3-44
XY-CH number
X-axis CH number
Y-axis CH number
Active XY-CH
XY-CH number
: XY-CH number.
: Displays the selected CH operating in RANGE mode or SPAN mode.
: Analog CH number set on the X(Y)-axis.
: Annotation of the analog CH set on the X(Y)-axis is displayed. When
the number of annotation characters is larger than the display area, all
the character strings are displayed by scrolling to the left.
: Current measured value (instantaneous value) is displayed.
X-axis CH annotation
Y-axis CH annotation
Inactive XY-CH
X-axis measured value
Y-axis measured value
X-axis measured value
Y-axis measured value
