CHAPTER 3 Settings and Measurement
(4)-5 Alarm settings
Alarm level settings
This is used to set the alarm generation conditions and output destination, etc.
When the conditions specified are met, the alarm output terminal (for which an output destination number
must be specified for each channel) sets off an alarm.
For the CH condition settings, refer to "Trigger Level Settings/Alarm Level Settings" described below.
Alarm occurrence hold
If "Alarm occurrence hold" is selected, and once the established conditions have been met, the alarm status
will not be cleared, regardless of whether or not the conditions continue to be met.
(Press the [CURSOR] key to cancel it)
Output 1 selection
Select Alarm output 1 or Trigger output.
Setting
Alarm output 1
Trigger output
3-100
Alarm output 1 is output from the Alarm output 1/Trigger output terminal.
Trigger is output from the Alarm output 1/Trigger output terminal.
Description
