Summary of Contents for GRAPHTEC miid LOGGER GL860

Page 1 GL860 USER’S MANUAL MANUAL NO.GL860-UM-151...
Page 2 To Ensure Safe and Correct Use To Ensure Safe and Correct Use • To ensure safe and correct use of the GL860, read this manual thoroughly before use. • After having read this manual, keep it in a handy location for quick reference as needed. •...
Page 3 0.75 mm2. When using the GL860 in an environment where • After checking that smoke is no longer being generated, grounding is not possible, ensure measured is no greater contact your sales representative or nearest Graphtec than 50 V (DC or rms). vendor to request repair. •...
Page 4 Such action may cause the GL860 to break down. • Such action may impair the GL860’s performance. • Clean off any soiled areas using a soft dry cloth. Use prohibited Use prohibited Be sure to use the Graphtec-supplied AC adapter. • It will damage this device. Use prohibited...
Page 5 Safety Precautions Safety Precautions CAUTION CAUTION Do not touch the input terminals after the signal cable is Confirm the power of supplier of signal is turned off connected to the measuring objects that are containing before connecting the input cables to the input terminal the voltage.
Page 6 Safety Precautions Safety Precautions CAUTION CAUTION When using the wireless LAN unit (optional), please When using the wireless LAN unit (optional) in a note the following: medical establishment, please note the following rules: • • If you have an implantable pacemaker or implantable Please turn off the power of this product in hospital wards.
Page 7 Introduction Introduction Thank you for purchasing the GL860 midi LOGGER. Please read this manual thoroughly before attempting to use your new product to ensure that you use it correctly and to its full potential. Notes on Use Be sure to read all of the following notes before attempting to use the GL860 midi LOGGER. 1.
Page 8 This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter. 4. Notes for Safe Operation (1) Be sure to use the Graphtec-supplied AC adapter. In environments where there is a lot of noise or where the power supply is unstable, we recommend that you ground the GL860.
Page 9 (1) All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, without the prior written permission of Graphtec Corporation. (2) The specifications and other information in this manual are subject to change without notice.
Page 10 Contents Contents To Ensure Safe and Correct Use ............Safety Precautions .
Page 11 Contents Chapter 3 Settings and Measurement Name of each screen part and functions ..........3-2 Key Operations .
Page 12 Contents Chapter 5 Specification Standard Specifications ............5-2 Standard Specifications .
Page 13 Chapter 1 General Description This chapter provides a general description of the GL860 and its features. SECTION IN THIS CHAPTER Overview Features Supported Input Terminals Operating Environment Notes on Temperature Measurement Notes on Using the Monitor Changing the Display Language Power frequency settings Custom Menu Settings...
Page 14 CHAPTER 1 General Description Overview The GL860 is a compact, lightweight, multi-CH, and multi-purpose data logger with a 7-inch color display. There are three types of terminal units with 20 channels. By using the expansion terminal base, it is possible to measure up to 200 channels. The GL860 can save the high-capacity measurement data directly in the internal memory or SD CARD.
Page 15 CHAPTER 1 General Description Supported Input Terminals This section describes the input terminals supported by this unit. ① Standard 20CH screw terminal ② Standard 20CH screwless terminal (B-563SL) (B-563) ③ Standard 30CH screwless terminal ④ Withstand high-voltage high-precision terminal (B-563SL-30) (B-565) ⑤...
Page 16 CHAPTER 1 General Description Operating Environment This section explains the operating environment for the GL860. Ambient Operating Conditions (1) Ambient temperature and humidity (the GL860 must be operated within the following ranges.) • Temperature range: 0 to 45°C (0 to 40°C when a battery pack is mounted, 15 to 35°C when battery is being charged) •...
Page 17 CHAPTER 1 General Description Configuration When in Use Do not use the GL860 standing upright or at an angle. It must always be laid flat or inclined on the stands. <Usage Configuration> 90° Laid flat Opening the stands Inclined on the stands CAUTION •...
Page 18 CHAPTER 1 General Description Notes on Using the Monitor The monitor is an LCD display unit, so the display will vary depending on the operating environment. If the screen saver function is used, it will operate and clear the screen if no operations are performed during the preset time.
Page 19 CHAPTER 1 General Description Custom Menu Settings The GL860 allows you to customize the menus that are displayed. By turning off functions that are not used, they will not appear in the settings menu, etc. To change this setting, set “Custom Menu” which is displayed when the GL860 is first started, or “Custom Menu” in the “OTHER Menu”.
Page 20 Chapter 2 Checks and Preparation This chapter explains how to check the main module's external casing and accessories, and how to prepare the main module for operation. SECTION IN THIS CHAPTER Checking the Outer Casing Checking the Accessories Mounting and removing each terminal Mounting the Extension Terminal Base (Optional) and Extension Terminal Cable (Optional) Nomenclature and Functions Connecting the Power Cable and Turning on the Power...
Page 21 CHAPTER 2 Checks and Preparation Checking the Outer Casing After unpacking, check the GL860's outer casing before use. In particular, please check for the following: • Surface scratches • Other flaws such as stains or dirt Checking the Accessories After unpacking, check that the following standard accessories are included. Standard Accessories Item Remarks...
Page 22 CHAPTER 2 Checks and Preparation Mounting and removing each terminal This section describes the mounting and removing procedure of the Standard 20CH screw terminal. The Standard 20CH screwless terminal, Standard 30CH screwless terminal and Withstand high-voltage high-precision terminal can be removed and attached in the same way. CAUTION When mounting or removing the standard terminal or Withstand high-voltage high-precision terminal, please make sure that the GL860’s power is turned OFF.
Page 23 CHAPTER 2 Checks and Preparation CAUTION The specifications of the Standard 20CH screw terminal (or Standard 20CH/30CH screwless terminal) and the Withstand high-voltage high-precision terminal are different, so please check the specifications before use. Removing Pull out the terminal in the direction of the arrow while pressing the lock portion (place) under theStandard 20CH screw terminal.
Page 24 CHAPTER 2 Checks and Preparation Mounting the Extension Terminal Base (Optional) and Extension Terminal Cable (Optional) 2.4.1 Mounting the extension terminal base This section describes how to mount the extension terminal base. CAUTION When mounting the extension terminal base on the GL860, please make sure that the GL860’s power is turned OFF. Prepare the extension terminal base and the extension terminal connection cable which are sold as optional items.
Page 25 CHAPTER 2 Checks and Preparation Connect the extension terminal connection cable to the extension terminal base. * Insert the extension terminal connection cable until the cable is securely locked. * Connect in accordance with the connector shape. Extension terminal connection cable Connect one end of the extension terminal connection cable to the terminal connector on the GL860.
Page 26 CHAPTER 2 Checks and Preparation 2.4.2 Mounting multiple extension terminals The mounting procedure of the multiple extension terminal set is described. CAUTION Mounting multiple extension terminals make sure the GL860’s power is OFF when mounting the extension terminals on the GL860.
Page 27 CHAPTER 2 Checks and Preparation Connect the extension terminal connection cable to the extension terminal base. * Insert the cable connector until it is securely locked. * Connect in accordance with the connector shape. Extension terminal connection cable Connect one end of the extension terminal connection cable to the GL860. * Insert the cable connector until it is securely locked.
Page 28 CHAPTER 2 Checks and Preparation When adding the extension terminal bases Unit 10 (CH 181 to 200) Unit 2 (CH 21 to 40) Unit 1 (CH 1 to 20) CAUTION • When the terminals are added, please connect continuously them without disconnecting terminals. If there is a disconnected terminal, subsequent terminals are not recognized.
Page 29 CHAPTER 2 Checks and Preparation Connect each between the extension terminal bases with the extension terminal connection cable. * Insert the extension terminal connection cable until the cable is securely locked. Install the extension terminal bases in a stable location and be careful not to fall. Unit 2 (CH21 to CH40) Unit 1 (CH1 to CH20) Extension terminal connection cable...
Page 30 CHAPTER 2 Checks and Preparation Nomenclature and Functions This section describes the names and functions of parts of the GL860. AC adapter jack External input/output terminals • LOGIC/PULSE • EXT TRIG/SAMPLE Operation status LED • ALARM • POWER: ON when the power is ON PC interface Blinking while accessing the memory terminals...
Page 31 CHAPTER 2 Checks and Preparation Connecting the Power Cable and Turning on the Power This section describes how to connect the power cable and turn on the power. The connection method will vary depending on the type of power supply used. Connecting to an AC Power Supply Use the AC cable and AC adapter that are provided as accessories.
Page 32 CHAPTER 2 Checks and Preparation Connecting to a DC Power Supply Use the optional DC drive cable (B-514: Option). CAUTION • Use a power supply within the 8.5 to 26.4 VDC range. • For DC drive cable, please be sure to use the B-514. Configure the tip of the DC drive cable (B-514: 2m) to enable it to be connected to the DC power supply.
Page 33 CHAPTER 2 Checks and Preparation Connecting the Signal Input Cables This section describes how to connect the signal input cables. CAUTION During wiring, confirm that the signal’s supply source is turned OFF to prevent electrical shocks. Also, position the GL860 input cable away from any power lines and ground cables. Terminal Configuration and Signal Types (Standard 20CH screw terminal: B-563) CH20 Connection diagram (Standard 20CH screw terminal: B-563)
Page 34 CHAPTER 2 Checks and Preparation Item Description Input configuration Isolated input, scanning Measurement range 20, 50, 100, 200, 500 mV/F.S.; 1, 2, 5, 10, 20, 50, 100 V; 1-5V/F.S. Thermocouples K, J, E, T, R, S, B, N, C (W: WRe 5-26) A/D resolution 16-bit (Effective resolution: Approx.
Page 35 CHAPTER 2 Checks and Preparation Item Description Input configuration Isolated input, scanning Measurement range 20, 50, 100, 200, 500 mV/F.S.; 1, 2, 5, 10, 20, 50, 100 V; 1-5V/F.S. Thermocouples K, J, E, T, R, S, B, N, C (W: WRe 5-26) A/D resolution 16-bit (Effective resolution: Approx.
Page 36 CHAPTER 2 Checks and Preparation Item Description Input configuration Isolated input, scanning Measurement range 20, 50, 100, 200, 500 mV/F.S.; 1, 2, 5, 10, 20, 50, 100 V; 1-5V/F.S. Thermocouples K, J, E, T, R, S, B, N, C (W: WRe 5-26) A/D resolution 16-bit (Effective resolution: Approx.
Page 37 CHAPTER 2 Checks and Preparation + ....High-voltage terminal (terminal for high-voltage input signals) – ....Low-voltage terminal (terminal for low-voltage input signals) b ....Dedicated terminal when connecting resistance bulb * Resistance bulb input terminals A (+) and B (-) are isolated within each channel. Terminal b is shorted within all channels.
Page 38 CHAPTER 2 Checks and Preparation Logic Alarm Cable Connection and Functions This section describes how to connect the logic alarm cables and the functions of cable. CAUTION During wiring, confirm that the signal’s supply source is turned OFF to prevent electrical shocks. Also, position the GL860 input cable away from any power lines and ground cables.
Page 39 CHAPTER 2 Checks and Preparation Internal equivalent circuit of I/O circuit Alarm output Maximum ratings of the transistor for alarm output VCEO (Collector-emitter voltage) : 30 V IC (Collector current) : 0.5 A + 5 V PC (Collector dissipation) : 0.2 W * The maximum ratings must not be exceeded.
Page 40 CHAPTER 2 Checks and Preparation Wiring Cable tips are bare tips. Perform wiring for the necessary functions. Signal Name Channel Number Wire Color Logic/Pulse input Orange with red dotted line Orange with black dotted line Grey with red dotted line Grey with black dotted line Alarm output White with red dotted line...
Page 41 CHAPTER 2 Checks and Preparation Mounting the SD Memory Card How to insert the SD memory card Insert the SD memory card into the SD CARD slot. CAUTION When the optional wireless LAN unit is installed, the SD memory card cannot be inserted. Remove the SD CARD protective cover.
Page 42 CHAPTER 2 Checks and Preparation Insert and close the protective cover into the upper hole and lower hole for the SD CARD protective cover. SD CARD Protective cover How to remove the SD memory card Make sure that the SD memory card displayed on the screen is green, and the POWER LED lights up before removing it.
Page 43 CHAPTER 2 Checks and Preparation 2.10 Installing the Wireless LAN Unit (B-568: Option) To connect the GL860 to the wireless LAN, attach the wireless LAN unit to the wireless LAN connection terminal. CAUTION • When the SD memory card has been inserted into the SD CARD slot, please remove the SD memory card. •...
Page 44 CHAPTER 2 Checks and Preparation Align the wireless LAN unit to the wireless LAN connection terminal and the fixed guide and then insert the wireless LAN unit until the unit is locked. Wireless LAN unit CAUTION When the wireless LAN unit has been inserted, please be careful when handling so as not to hit and drop. Removing the wireless LAN unit Turn OFF the power and then remove the wireless LAN unit.
Page 45 CHAPTER 2 Checks and Preparation 2.11 Connecting to a PC Use the USB or LAN Interface to connect the GL860 to a PC. Connection Using a USB Cable Connect between the GL860 and PC with the USB cable. USB cable CAUTION The USB connector is adjacent to the LAN connector.
Page 46 CHAPTER 2 Checks and Preparation LAN Connection Use a LAN cable to connect the GL860 to a PC. LAN cable Cable Types Use a crossing cable when connecting directly to a PC, without using a hub. GL860 Use a straight cable when using a hub. GL860 GL860 2-27...
Page 47 CHAPTER 2 Checks and Preparation Connection through the wireless LAN (Option) Insert the wireless LAN unit (B-568: Option). For the insertion, refer to "2.10 Installing the Wireless LAN Unit (B-568: Option)". Access point (operating as a base unit): The following devices and operating environments are required to connect the GL860 to a PC or smartphone via wireless LAN.
Page 48 CHAPTER 2 Checks and Preparation 2.12 Using the Battery Pack (B-573/B-569: Option) • The B-573/B-569 option is the only battery type that can be used with the GL860. • Refer to "5.3 Accessories/Optional Accessories" for information on the battery run time. •...
Page 49 CHAPTER 2 Checks and Preparation Attach the battery cover. Charging the Battery Expected time required for charging • Battery pack x 1: approx. 5 hours • Battery pack x 2: approx. 10 hours The battery pack is charged by mounting it in the GL860 are attaching AC adapter to the GL860. Mount the battery pack in the GL860 (see “Mounting the Battery Pack”...
Page 50 CHAPTER 2 Checks and Preparation 2.13 Connecting the Humidity Sensor Connect the + and – lead wires of the humidity sensor (B-530: Option) to the desired terminals, and then insert the round connector into the 5V OUT connector on the GL860. Brown Humidity Sensor White...
Page 51 CHAPTER 2 Checks and Preparation 2.14 Precautions to Observe When Performing Measurement Please be sure to read the following carefully in order to prevent electric shocks or shorts. CAUTION • Do not apply radio-frequency signals with high voltage (50 KHz or above). •...
Page 52 CHAPTER 2 Checks and Preparation [ Voltage measuring ] [ Temperature measuring ] Thermocouple Thermocouple Thermocouple Input Circuit Diagram for Analog Input (Voltage, Thermocouples) 50Ω 500kΩ 0.05μF 0.05μF 500kΩ 50Ω Channel Switching Relay CAUTION Capacitors have been incorporated into the input circuit to increase the noise-elimination capability. After voltage measurement, when the inputs have been disconnected, there will still be some electric charge remaining.
Page 53 CHAPTER 2 Checks and Preparation [ Voltage measuring ] [ Temperature measuring ] Thermocouple Thermocouple Thermocouple Input Circuit Diagram for Analog Input (Voltage, Thermocouples) 50Ω 500kΩ 0.05μF 0.05μF 500kΩ 50Ω CAUTION Capacitors have been incorporated into the input circuit to increase the noise-elimination capability. After voltage measurement, when the inputs have been disconnected, there will still be some electric charge remaining.
Page 54 CHAPTER 2 Checks and Preparation 2.15 Noise Countermeasures Be sure to connect the chassis GND of the measurement object. It may become effective by ensuring that the chassis GND wire of the measurement object is connected to good ground. Measurement object GL860 Thermocouple Connect the signal chassis GND to the measurement device chassis ground.
Page 55 CHAPTER 2 Checks and Preparation 2.16 When Fixing the GL860 Main Unit Fixing the GL860 Main Unit When fixing the GL860 main unit to prevent the dropout of the GL860, the two nuts on the back must be used. * Recommended tightening torque: 14kgf/cm When fixing the GL860, it must be installed in a horizontal state rather than in a vertical or inclined state.
Page 56 CHAPTER 2 Checks and Preparation 2.17 Setting the Date and Time If you are using the GL860 for the first time, charge the internal rechargeable battery and set the date and time. CAUTION If the GL860 is not used for approximately six months, the internal rechargeable battery may be discharged and the date and time may revert to the initial settings.
Page 57 Chapter 3 Settings and Measurement This chapter describes the setting and measurement procedures for the GL860. SECTION IN THIS CHAPTER Name of each screen part and functions Key Operations Operation Modes Setting Menus WEB Server Function List of Error Codes...
Page 58 Chapter 3 Settings and Measurement Name of each screen part and functions 4. Device access display (Internal memory) 5. Device access display (SD memory card / wireless LAN display) 1. Simplified message display 6. Remote lamp 2. TIME/DIV 7. Key lock display 3.
Page 59 Chapter 3 Settings and Measurement 2. Time/DIV display area Displays the current time scale. 3. Sampling interval The currently set sampling interval is displayed. 4. Device access display (Internal memory) : The internal memory is not being accessed. : The internal memory is being accessed. The POWER LED also blinks while accessing the internal memory.
Page 60 Chapter 3 Settings and Measurement 7. Key lock display : Not in key lock status. Normal operations are enabled. : Key lock status. All the keys are locked. Refer to "13. To cancel key lock by password" in "3.4 Setting Menus" for details on the key lock. 8.
Page 61 Chapter 3 Settings and Measurement <Calculation mark> Calculation mark Calculation source display As shown below, the CHs with the calculation mark is the CH of calculation between channels. The digital display of the calculation CH shows the value of the analog CH that is the source of the calculation. (Calculation source display).
Page 62 Chapter 3 Settings and Measurement 11. Quick settings You can change the settings for dividing the waveform display. Use the " " keys to activate the Quick setting and the " " keys to change values. For details, refer to "12. Quick setting" in "3.4 Setting Menus". 12.
Page 63 Chapter 3 Settings and Measurement 14. File name display area <During data capture> A capture file name is displayed during capture. * If the ring recording setting is ON, a file name displayed during capture ends with "_RINGx" (x represents a number) but the actual file name does not include "_RINGx".
Page 64 Chapter 3 Settings and Measurement * Remaining time more than 99999 hours is displayed as "++++:++:++". <During data replay> Displays the display position, cursor position, and trigger position graphically. Cursor A position Cursor B position All capture data The range for which a waveform is currently displayed...
Page 65 Chapter 3 Settings and Measurement Key Operations This section describes key operations. 1. CH GROUP 2. SELECT 3. TIME/DIV 4. MENU 5. QUIT 6. Direction Keys 7. ENTER 8. FAST REWIND/FORWARD key (KEY LOCK) 9. START/STOP （USB DRIVE） 13. FILE 14.
Page 66 Chapter 3 Settings and Measurement If you press and hold this key, the channel group is displayed. You can set it directly for the channel group you want to select. Use the “ ” keys to select a channel group, and press the [ENTER] key to confirm. * * Channel groups that cannot be selected are displayed in light color.
Page 67 Chapter 3 Settings and Measurement (3) TIME/DIV Press the left/right key of the [TIME/DIV] key to change the time axis display width. TIME/DIV display (4) MENU Open the settings window to capture data. For details on settings, refer to “3.4 Setting Menus”.
Page 68 Chapter 3 Settings and Measurement (6) Direction Keys This key is primarily used for the following operations. • To move a menu or setting item during menu configuration. • To move the cursor during replay. • To move the active channel in the Waveform + Digital. (“ ”...
Page 69 Chapter 3 Settings and Measurement (9) START/STOP （USB Drive Mode） This key performs the following two operations: <Starts/stops capture> • When free-running, start recording. • If recording is in progress, recording is stopped. USB Drive Mode Operation Procedure In the "USB Drive Mode", the internal memory and SD memory card can be check on a PC as an external storage device.
Page 70 Chapter 3 Settings and Measurement (10) REVIEW This key is used to replay captured data. • During Free Running, captured data is replayed. The screen used to specify the data replay source file appears; specify the file you want to replay. •...
Page 71 Chapter 3 Settings and Measurement (11) DISPLAY This key is used to switch the screen mode. When free-running (when the recording is stopped), data capturing, and data replaying during the capture, the screen mode can be switched. Pressing this key switches the screen display as follows: <When free-running and data capturing>...
Page 72 Chapter 3 Settings and Measurement <Data replay during capture> < Replay screen display> <2-screen replay display> CAUTION For CSV-formatted data, only the data captured by this GL860 can be replayed. Also, when the data captured in CSV format is replayed, the unit of the temperature data is displayed in “deg C” rather than “°C”.
Page 73 Chapter 3 Settings and Measurement (13) FILE This key is used to perform the file-related operations. • Performs the operations (copy and delete, etc.) for the internal memory and SD CARD. • Performs the screen copy • Saves all data or data between cursor A and cursor B during replay (can be set during replay only) •...
Page 74 Chapter 3 Settings and Measurement Basic Procedures Used in Settings The following are basic operation procedures for settings. Press the [MENU] key to open each menu. You can move between menu tabs by pressing the [MENU] key several times or by pressing the "...
Page 75 Chapter 3 Settings and Measurement Operation Modes You can check the system operation status in the status message display. < Free Running > < Capturing > <Replaying while capturing data> < Replaying > Operation Description Simple message display Free Running Startup status, or data is not being captured.
Page 76 Chapter 3 Settings and Measurement 1. Free Running In free-running, you primarily perform the settings for data capture. You can check the currently input signal in the waveform or digital value. Main operations available during Free Running Measurement parameters settings The [MENU] key is used to change various setting items in configuration menus.
Page 77 Chapter 3 Settings and Measurement Operations available during capture SPAN/POSITION/TRACE change Press the [ENTER] key to open the Span/Position/Trace settings and make settings. Screen display mode switch Used to change the screen mode with the [DISPLAY] key. Replay while capturing The [REVIEW] key is used to replay captured data in two windows at the same time.
Page 78 Chapter 3 Settings and Measurement Main operations to replay captured data SPAN/POSITION/TRACE replay Press the “ENTER” key to open the [SPAN/POSI/TRACE] settings and change the settings. Operation in the menu during data capture Perform cursor movement and data search with the [MENU] key. Cursor movement You can switch between cursors A and B using the [CURSOR] key.
Page 79 Chapter 3 Settings and Measurement Setting Menus When you press the [MENU] key during Free Running, the following menu screens appear. DATA TRIG ALARM OTHER 1. AMP settings This menu is used to specify input signal-related settings. <Analog settings> <Logic Pulse settings> <Calculation settings>...
Page 80 Chapter 3 Settings and Measurement Setting Selections available Analog Input Standard terminal / Screwless Off, DC, TEMP, RH terminal Withstand high-voltage high-precision terminal 20 ・ 50 ・ 100 ・ 200 ・ 500mV、 1 ・ 2 ・ 5 ・ 10 ・ 20 ・ 50 ・ 100V、 1-5V Standard 20CH screw Range Voltage...
Page 81 Chapter 3 Settings and Measurement Setting Selections available Logic/Pulse Mode Off, Logic, Pulse Logic Filter Off, On Misc. Waveform color 0 to 31 for each of red, green, blue (RGB) setting Trace setting Off, On Pulse Input Off, Revolution counts, Counts, Inst. Filter Off, On Slope...
Page 82 Chapter 3 Settings and Measurement Switching displays Switching between Analog, Logic/Pulse and Calculation is as follows. Select the channel to be displayed from the amplifier.For analog channels, the items displayed change depending on the number of terminals connected. Select Target Channel CHx - CHy Displays the analog channel.
Page 83 Chapter 3 Settings and Measurement 1-2. Sensor This is used to select the type of thermocouple to be connected when the temperature is input. Terminal Unit Selection item Description Thermocouple: TC-K ・ TC-J ・ TC-T ・ TC-R ・ TC-E ・ TC-B ・ TC-S ・ TC-N ・ TC-C Standard 20CH screw terminal Sensor (B-563)
Page 84 Chapter 3 Settings and Measurement <Temperature Ranges> Resolution Measurement range Type Humidity Range R ／ S 0 ～ 100℃ 100℃ F.S. 0.01℃ 0 ～ 500℃ 500℃ F.S. 0.05℃ R ： 0 ～ 1600℃ 2000℃ F.S. 0.1℃ S ： 0 ～ 1760℃ 500℃...
Page 85 Chapter 3 Settings and Measurement If the filter setting is 5, The moving average is "D=((n-4)+(n-3)+(n-2)+(n-1)+ n)÷5". If the sample interval exceeds 30 seconds, the average value of data obtained in a sub-sample (30 seconds) is used. 1-5. EU (Scaling settings) This is used to convert the measured signals to other units.
Page 86 Chapter 3 Settings and Measurement • If a message window opens, follow the instruction in the message to change the setting value. • The Scaling function performs calculation using a ratio of the Meas. Value and EU Output Value settings. •...
Page 87 Chapter 3 Settings and Measurement 1-7. Logic / Pulse This is used to select the processing method for digital input. Selection item Description Digital input measurement is disabled. Logic Digital input is processed as logic signals. Pulse Digital input is processed as pulse signals. 1-8.
Page 88 Chapter 3 Settings and Measurement 1-11. EU (Scaling settings) This is used to convert the measured signals to other units. This setting is available only if Pulse is selected in "1-7.Logic / Pulse". Setting Description EU Function Sets the scaling function to ON or OFF. Meas.
Page 89 Chapter 3 Settings and Measurement 1-12. Misc. <For Pulse> <For Logic> Setting Description Waveform Color Setting 0 to 31 for each of red, green, blue (RGB) Line Thickness Setting 1 to 8 dots Trace This is used to set the waveform display. Pulses per revolution 1 to 10000 When setting the pulse input to the number of revolutions, set the number of pulses per revolution.
Page 90 Chapter 3 Settings and Measurement Calculation settings 1-13. Calculation Make settings related to calculation. Setting Description Setting Off, On (when inter-CH Op. setting is a formula or 4-point input) Misc. Set annotation, waveform color, line thickness and trace. <Calculation Off settings> <Calculation formula settings>...
Page 91 Chapter 3 Settings and Measurement Setting Description Set the coefficient of CH-Y. Set the offset value of the calculated value. Auto adjustment Adjust the span range based on the displayed measurement value. Upper limit Set the upper span value to display the waveform. The set value is the value for the calculation result.
Page 92 Chapter 3 Settings and Measurement Setting Description Upper limit Set the upper span value to display the waveform. The set value is the value for the calculation result. Lower limit Set the lower span value to display the waveform. The set value is the value for the calculation result. Unit selection Select the unit for displaying the calculation result.
Page 93 Chapter 3 Settings and Measurement Decimal point position Four decimal places +9.9999 -9.9999 Three decimal places +99.999 -99.999 Two decimal places +999.99 -999.99 One decimal place +9999.9 -9999.9 Five-digit integer +99999. -99999. If the calculation result is outside the valid range, change the decimal point position. Copy settings Copy the AMP settings of the specified CH to any CH.
Page 94 Chapter 3 Settings and Measurement ● Pt100, JPt100, and Pt1000 settings cannot be copied to amplifiers that do not support RTDs. ● Alarm and trigger settings can be copied if they are enabled in the custom menu. (1)-15 How to specify copy channel <...
Page 95 Chapter 3 Settings and Measurement When the settings are copied, the copy mode ends. If you change the type of the copy source CH (Analog, Logic/Pulse, or Math), the copy destination selection that was previously selected will be cleared. (1)-16 How to specify the copy channel range Start copying the AMP tab.
Page 96 Chapter 3 Settings and Measurement The specified CH will be copied. When the settings are copied, the copy mode ends. (1)-17 Copy Options In addition to the AMP settings, you can also choose whether to copy the trigger (level value) and alarm settings at the same time with the copy function.
Page 97 File Type GBD, CSV Set the file format used to save data. GBD: Creating a data file in Graphtec’s proprietary binary format * It is not possible to change the data. CSV: Creating a data file in text format Name Type Auto, Arbitrary, Sequential number Set how a data file should be named.
Page 98 Chapter 3 Settings and Measurement 2-1. Sampling interval This is used to set the sampling interval for data capture. The table below shows the number of measuring channels* and sampling interval values that can be set. If data fluctuate due to noise, set the sampling interval to a value that enables the digital filter function. Number of Measuring Sampling Interval which enables Allowed Sampling Interval...
Page 99 Chapter 3 Settings and Measurement Input signal Sampling interval Shortest interval External Sampling pulse Data for this Data for this Capture data • If the external sampling function is On, the external input cannot be selected for the trigger setting. If the external input has already been set, the trigger will be set to Off.
Page 100 Chapter 3 Settings and Measurement 2-4. Captured data file name This is used to select the name of a file or folder to which you want to save capture data. <If the naming method is Auto> <If the naming method is Arbitrary> <If the naming method is Sequential>...
Page 101 Chapter 3 Settings and Measurement 2-5. Ring/Relay capturing settings Sets the ring relay function. <Ring/Relay Ring Off> <Ring/Relay Ring> <Ring/Relay Relay/Capacity> <Ring/Relay Relay/Time> Setting Selections available Ring/Relay capturing Set the capturing function. Off: The capturing function is disabled. Ring: The ring capturing is executed. (For details, refer to "2-6. Ring capture setting".) Relay: Performs continuous capturing by separating files by the set file size unit or capturing time without missing data.
Page 102 Chapter 3 Settings and Measurement Ring Capture Function Start capturing data Captured data is saved into the File 1. When the specified number of data are saved into the File 1, the captured data is saved into the File 2. The number of data is specified in the “Ring Capture Points”...
Page 103 Chapter 3 Settings and Measurement Relay Capture Function Files are separated by the set file size or capturing time unit and captured continuously without missing any data. (The capacity for one file is 10MB to 2GB, and the capturing time is 1 hour to 24 hours.) When the memory loop is set to Off Start capturing data Captured data is saved into the File 1.
Page 104 Chapter 3 Settings and Measurement Start capturing data Captured data is saved into the File 1. Data is captured to File 2 when capturing up to the time or capacity set in "Relay mode time". At this point, the remaining capacity for capturing the destination is 6 files or more. There- fore, the file is switched as it is to continue.
Page 105 Chapter 3 Settings and Measurement • When the ring capturing function is set to On, the backup function is not available. • The memory that is the same as the capture destination cannot set as the backup save folder. • It takes a time for writing after recoding was stopped when many channels are recoding, when interval sampling is fast, when backup interval is long, because the backup data size becomes large.
Page 106 Chapter 3 Settings and Measurement 3. TRIG settings Set the trigger conditions. Setting Selections available Start Side Source Setting Off, Level, Alarm, External Input, Date, Weekly, Time Level Mode Analog: Off, H, L, Window In, Window Out Logic: Off, H, L Pulse: Off, H, L, Window In, Window Out Combination Level OR, Level AND, Edge OR, Edge AND...
Page 107 Chapter 3 Settings and Measurement 3-2. Stop side source setting This is used to specify trigger conditions to stop data capture. Selection item Description Stops capturing data unconditionally when you press the [START/STOP] key. Level Stops capturing data when a specified level is reached. ->...
Page 108 Chapter 3 Settings and Measurement 4. ALARM settings Make alarm settings. Setting Selections available Mode Analog: Off, H, L, Window In, Window Out Logic: Off, H, L Pulse: Off, H, L, Window In, Window Out Level Set numeric value Output 1, 2, 3, 4 Misc.
Page 109 Chapter 3 Settings and Measurement 4-5. Alarm History Set how to use the Alarm History function. Alarm History function When the Alarm History function is enabled, up to the latest 100 events for alarm occurrence/clearing can be saved. During data capturing, you can check the events that have occurred. During data replaying, you can check the event that occurred and move the cursor to the point where the event occurred.
Page 110 Chapter 3 Settings and Measurement Alarm History screen The Alarm History screen can be displayed by pressing the "DISPLAY" key several times during data capturing. When capturing data When replaying data <Waveform + Digital> <Waveform + Digital> <Waveform enlargement> <Alarm History> <Digital + Calculation>...
Page 111 Chapter 3 Settings and Measurement Description of the alarm history screen <When replaying data> <Capturing> Alarm occurrence/clearing Alarm occurrence/clearing Event date and time Event date and time Cause of event Cause of event Selection cursor Display Description Event date and time Date and time when the alarm event occurred.
Page 112 Chapter 3 Settings and Measurement Trigger level settings/Alarm level settings Specifies detailed conditions for each channel when the start and stop side source settings are Level. The configuration of the level trigger is shown in the figure below. <For trigger> <For alarm>...
Page 113 Chapter 3 Settings and Measurement Level and Edge operations In the Level operation, a trigger is assumed to be generated if the trigger/alarm conditions are met when the [START] key is pressed. In the Edge operation, even if the trigger/alarm level achieves the trigger/alarm generation level when the [START] key is pressed, it is not considered the trigger/alarm condition is satisfied if the level does not exceed the set level.
Page 114 Chapter 3 Settings and Measurement Dead zones of trigger and alarm levels Trigger and alarm levels are provided with a dead zone to prevent false detection due to noise. The following figure shows the dead zone. Mode: Rising A trigger (alarm) does not occur because the input signal is not Trigger (alarm) point below the dead zone level.
Page 115 Chapter 3 Settings and Measurement (4)-6 How to specify the channel to copy trigger settings Select a level value in the START source setting or STOP source setting on the “TRIG” tab. Open the level settings. Start copying settings. Select the source CH. The source CH will be marked with a “*” mark. If you select the same CH again, the copy source will be cancelled.
Page 116 Chapter 3 Settings and Measurement Execute the copy. The copy will be executed. When you finish copying the settings, the copy mode will end. (4)-7 How to specify the copy channel range Select a level value in the START SOURCE setting or STOP SOURCE setting on the “TRIG” tab. Open the level settings.
Page 117 Chapter 3 Settings and Measurement Set the range of source and destination CHs, then press “OK.” If you clear the selection, the currently selected CH will be cleared and you will return to the previous screen. Verify that the source CH has a “*” mark and the destination CH has an “>” mark and click Execute. CHs with different AMP settings are grayed out and cannot be copied.
Page 118 Chapter 3 Settings and Measurement (4)-8 How to specify the channel to copy alarm settings Copy the settings on the ALARM tab. Select the source CH. The source CH will be marked with a “*” mark. If you clear the selection, the currently selected CH will be cleared and you will return to the previous screen. Specify the copy destination.
Page 119 Chapter 3 Settings and Measurement The copy will be executed. When you finish copying the settings, the copy mode will end. (4)-9 How to specify the channel range for copying alarm settings Copy the settings on the ALARM tab. Open the CH range selection. Set the source CH and copy the CH range and press “OK”.
Page 120 Chapter 3 Settings and Measurement Verify that the source CH has an “*” mark and the destination CH has an “>” mark and click Execute. The copy will be executed. When you finish copying the settings, the copy mode will end. 3-64...
Page 121 Chapter 3 Settings and Measurement 5. Interface settings This menu is used to specify conditions for PC connection. Setting Description USB ID 0 to 9 Host Name Character string: up to 15 characters Wireless LAN settings Wireless LAN Off, Station, Access point (Only when the wireless Restart Restart the wireless LAN function.
Page 122 Chapter 3 Settings and Measurement WLAN settings (Access point) Setting Description Wireless LAN Off, Station and Access point Restart Wireless LAN Restart the wireless LAN function. If you switch between the station and the access point, please perform a restart. AUTO SETTINGS WPS system Push button method, PIN method...
Page 123 Chapter 3 Settings and Measurement Setting Description WEB Servers Settings Web server function Off, On Port Number 0 to 65535 Basic authentication Off, On User name Enter up to 31-character string Password Enter up to 31-character string Mail Settings E-mail Send Settings Account Email address Enter up to 63-character string...
Page 124 Chapter 3 Settings and Measurement 5-1. USB ID Sets the USB ID number of GL860. Specify a number from 0 to 9 (default value: 0). To control more than one GL860 unit with one PC, assign a unique USB ID to each of them. 5-2.
Page 125 Chapter 3 Settings and Measurement 5-4. Station setting When connecting to the commercially available wireless LAN base unit and controlling multiple GL860s from a PC, the e-mail send function of the GL860 and Internet connection are available. (The following conditions are required to use them.) •...
Page 126 Chapter 3 Settings and Measurement <Operation procedure> Select the station, and then execute the wireless LAN restart. The "Wireless LAN restarting" is displayed and the restart is executed by the station setting. Set the automatic setting (WPS). The wireless LAN is automatically set in the WPS system. In the absence of the use of automatic configuration (WPS), it is necessary to undertake a manual configuration of the access point to be connected.
Page 127 Chapter 3 Settings and Measurement 5-5. TCP-IP setting IP address auto acquisition Use IP address auto acquisition Do not use Selection item Description IP address auto-acquisition Do not use, Use Do not use: When you do not use “IP address auto acquisition”, select “Do not use” and set the IP address, Subnet mask, Port number, etc.
Page 128 Chapter 3 Settings and Measurement <Operation procedure> Set the SSID. Enter in accordance with the procedure in "10. Text input" described below. By default, the identification name automatically generated from the GL860 name is displayed. Set the encryption method. WEP or WPA-PSK/WPA2-PSK settings can be performed. When the WIP system is selected, the [WEP] key is displayed.
Page 129 Chapter 3 Settings and Measurement Push button method <For station> <For access point> Selection item Description WPS method Select the push button method or PIN method. Push button method: Communication settings can be made simply by pressing the WPS button on both the base and remote unit.
Page 130 Chapter 3 Settings and Measurement 5.9. Network settings Make network settings for each server and client. New Line Code Specifies the line feed code. Selection item Description CR+LF Starts a new line with CR+LF code. Starts a new line with LF code. Starts a new line with CR code.
Page 131 Chapter 3 Settings and Measurement FTP Client settings Make the settings for the backup destination FTP server. <FTP client settings> Selection item Description FTP client Destination FTP server Enter the domain name or IP address of the FTP server. (Up to 127 characters) User name Enter the user name of the FTP account.
Page 132 Chapter 3 Settings and Measurement FTP server settings Set the GL860 to function as an FTP server. <FTP server settings> Selection item Description FTP server FTP server Function Off, On Set the FTP server function to Enable or Disable. On: Enables the FTP server function. Off: Disables the FTP server function.
Page 133 Chapter 3 Settings and Measurement WEB server settings Perform the WEB server settings. Selection item Description WEB server Web server Off, On function Set the WEB server function to Enable or Disable. On: Enables the WEB server function. Off: Disables the WEB server function. * When you want to disable the WEB server function for security reasons, set it to Off.
Page 134 Chapter 3 Settings and Measurement <Outgoing mail server settings> Selection item Description Outgoing Easy setting Select an Email template. mail server User: Make any settings. settings Easy sending: Emails are sent using our server. * You can send Emails without SMTP settings. gmail: The template for gmail settings is deployed.
Page 135 Chapter 3 Settings and Measurement CAUTION ● Once each notification is sent, the next notification will be sent at least one minute later. Notification events that occur while the notification is pending will be skipped. Regarding alarm notifications, alarms that occurred during the one-minute notification hold will be notified all at once at the next notification.
Page 136 Chapter 3 Settings and Measurement Selection item Description Network time Internet Time Off, On settings Set whether or not to use this function. Off: This function is not used. No time adjustment is performed. On: Use this function to adjust the time. NTP Server Character string: up to 127 characters Enter the domain name or address of the clock server (NTP server) to use.
Page 137 Chapter 3 Settings and Measurement 6. OTHER settings Various conditions can be set. Setting Selections available TEMP Settings Make function settings related to temperature. Screen settings Make function settings related to the screen display. System settings Make function settings related to the system operation. Japanese ・...
Page 138 Chapter 3 Settings and Measurement Custom menu Setting Selections available Select from list Select the function you want to use from the list. Select in Wizard Select the function you want to use in a Wizard format. 6-1. Temperature settings Make settings for functions related to temperature.
Page 139 Chapter 3 Settings and Measurement 6-2. Screen settings Make settings for functions related to screen display. Setting Selections available LCD brightness Bright, Middle, Dark Screen Saver Off, 10, 30 (sec.), 1, 2, 5, 10, 30, 60 (min.) Background Color Black, White 6-2-1.
Page 140 Chapter 3 Settings and Measurement 6-3-1. Date/Time Makes settings related to the GL860 clock. The internal clock (date and time) of the GL860 can be set. 6-3-2. AC Line cycle Set the frequency of the AC power supply to use. Selection item Description 50Hz...
Page 141 Chapter 3 Settings and Measurement Selection item Description The warm-up time is not displayed. 30 minutes The warm-up time is displayed for 30 minutes after the power is turned on. 1 hour The warm-up time is displayed for 1 hour after the power is turned on. 2 hours The warm-up time is displayed for 2 hours after the power is turned on.
Page 142 Chapter 3 Settings and Measurement <Example of operation procedure> An example of the operation procedure for easy capture setting is described below. Select the “Easy Capture Settings” and then press the [ENTER] key to display the following menu screen. When the settings (input, sensor, and range) are satisfied, select the “Next>>” and then press the [ENTER] key. The “Input, Sensor, and Range, etc.”...
Page 143 Chapter 3 Settings and Measurement 6-6. Custom menu Select the functions to be used with the GL860. By turning off unused functions, unused functions are not displayed in the Setting Menu, etc. Display item Description Select from list Select the functions you do not want to use from the function list. Select in Wizard Select whether or not to use each function while checking the function details for each function.
Page 144 Chapter 3 Settings and Measurement Selection item Description Operation Ring capturing function Select whether to use the ring capturing function. settings On: Used. Off: Not used. * For the ring capturing function, refer to “2-5. Ring/Relay capturing settings”. Relay capturing function Select whether to use the relay capturing function.
Page 145 Chapter 3 Settings and Measurement 6-7. Information Displays system information. Selection item Description Firmware version The version of the firmware installed in the GL860 is displayed. Revision The revision of the firmware installed in the GL860 is displayed. Pattern ROM version The revision of the character and image data in the GL860 is displayed.
Page 146 Chapter 3 Settings and Measurement 7. Span/Position/Trace settings When the [ENTER] key is pressed on the waveform display screen during Free-running, capturing, replaying while capturing, or replay, the "Span/Position/Trace" setting screen is displayed. [ENTER] key The span of the active CH that was selected when the [ENTER] key was just pressed is initially selected. <For Analog, Pulse, Calculation>...
Page 147 Chapter 3 Settings and Measurement 7-3. Auto span adjustment Automatically adjust the span value based on the displayed data. 7-4. Position Move the 0 position of the waveform. By pressing the " " and " " buttons, the 0 position of the waveform moves by 1 division of the chart grid. In practice, the span is adjusted so that the above action is achieved.
Page 148 Chapter 3 Settings and Measurement * About auto span adjustment The method of reflecting the span settings other than the standard CH differs depending on whether the auto span adjustment is executed in the span setting dialog or in the batch setting mode display. Place to execute Settings reflected In the span settings dialog...
Page 149 Chapter 3 Settings and Measurement 8. FILE menu The file operations can be performed by pressing the [FILE] key. The display items vary depending on the operation mode of free-running, replaying, and capturing. <Free-running status > <During replay or dual-screen replay status> <Capturing status>...
Page 150 Chapter 3 Settings and Measurement Operation mode Description Show Properties The detailed information (file name, date, time) of the file or folder is displayed. For GBD and CSV files, replay operations are also possible. Rename file/folder Rename the file or folder. You can select the file or folder and rename it.
Page 151 Chapter 3 Settings and Measurement Specify the copy destination. When you select "File/Folder copy" from the File operation, the copy destination selection/execution screen is displayed. Press the " " and " " keys to specify the copy destination folder. In this example, to set the copy destination to the SD CARD, press the "...
Page 152 Setting Description File Type Sets the file format used to save data. GBD: Creating a data file in Graphtec's proprietary binary format. * Data tampering can be prevented. CSV: Creating a data file in text format. Name Type Sets how a data file should be named.
Page 153 Chapter 3 Settings and Measurement Capturing destination Backup destination Other conditions SD CARD replacement SD CARD None Replaceable (Capturing side) When ring capturing is enabled. Impossible When external sampling is set. Impossible Internal memory Replaceable (Capturing side) When ring capturing is enabled. Impossible When external sampling is set.
Page 154 Chapter 3 Settings and Measurement 8-5. Execute (Screen Copy) Executes screen copy and saves it to an image file. Refer to page "8-4. Specify Save Destination (Screen Copy)" for details on specifying the save destination. 8-6. Save Saves the setting conditions of the GL860. <If the naming method is Auto>...
Page 155 Chapter 3 Settings and Measurement 9. File dialog This section describes how to specify the data save destination in the DATA menu, how to specify the data save destination in the FILE menu, and how to operate the file list. <Data save destination specification file dialog>...
Page 156 Chapter 3 Settings and Measurement 10. Text input Related to text input operations such as annotation, EU (scaling) unit and captured data file name input. <Character entering mode> <Clipboard mode> Operation selection Clipboard Character entering Operation mode Description Operation method Text input Upper case alphabet mode When the cursor key is moved to the uppermost part, the input character...
Page 157 Chapter 3 Settings and Measurement If the display language is other than “Japanese”, half-width kana mode cannot be used in “2. Character type selection”. 10-1. Clipboard The clipboard is a function that allows you to store the character string that you have entered once and enter the same character string repeatedly.
Page 158 Chapter 3 Settings and Measurement Select the " " and use the " " key to select the character string you want to paste from the clipboard. Select the character string you want to paste. Paste by pressing the "ENTER" key. Paste the character string.
Page 159 Chapter 3 Settings and Measurement 11. Data replay menu Select the data you want to replay from the "Data replay source" by pressing the [REVIEW] key and replay the captured data. <Select replay data source> Select items Description File Specify the file in the capture destination (save destination). Check data corruption Check if the captured file is damaged.
Page 160 Chapter 3 Settings and Measurement Setting Selections available Data search CH1 to 200, Logic, Pulse, Alarm, CALC * Logic and Pulse are displayed only if the Logic Pulse function is On in the AMP settings. *CALC is displayed only if the Calculation function is On in the AMP settings. CH1 to CH200 CH1-200 Logic...
Page 161 Chapter 3 Settings and Measurement 11-5. Cursor Sync Sets up the function that moves two cursors in synchronization. Selection item Description Cursors are not synchronized. Only the specified one cursor moves. Two cursors move in synchronization. Cursor A is always the fulcrum. * Cursor Synch is turned Off when you move a cursor using Move to Selected Position or perform Data Search.
Page 162 Chapter 3 Settings and Measurement Selection item Description Average Displays the simple average value of the data between cursors A and B. Displays the maximum value of the data between cursors A and B. Displays the minimum value of the data between cursors A and B. Displays the peak to peak (P-P) value of the data between cursors A and B.
Page 163 Chapter 3 Settings and Measurement 12. Quick setting <Free Running> <Replay data> Screen Operation mode Sign Description Waveform Free Running ZONE Using the key, change the zone division. Capturing ZONE Using the key, change the zone division. Replaying during ZONE Using the key, change the zone division.
Page 164 Chapter 3 Settings and Measurement 13. To cancel key lock by password A password can be set to GL860 to cancel the key lock. (No password is set at factory default.) <Operation flow> Set the password. Press the " ", and [ENTER] keys at the same time to display the password setting screen shown below. Specify a 4-digit password.
Page 165 Chapter 3 Settings and Measurement 14. QR code Click the "HELP" mark icon in the menu of the GL860 to display the QR code. This QR code allows you to access the FAQ Q&A on our website. If you have any problems, read the QR code with your smartphone, etc., and check the Q&A on our website. 3-109...
Page 166 Chapter 3 Settings and Measurement WEB Server Function The web browser allows operating and monitoring GL860 through an optional wireless LAN unit. • Supported Web browsers – Google Chrome (recommended) – Microsoft Edge – Firefox *The web server function may not work properly if your web browser is updated.If this happens, try using a different web browser.
Page 167 Chapter 3 Settings and Measurement Type in the URL (http://IP address/Index.html) in the address input field. The following pages are displayed. <Screen display> <Change settings> <File operation> Screen display ....Allows GL860 operation. Change settings ...You can check and change the settings of the GL860. File operation ....The data captured by GL860 can be downloaded to/deleted from the PC.
Page 168 Chapter 3 Settings and Measurement Change settings AMP settings DATA settings TRIGGER settings ALARM settings I/F settings OTHER settings AMP settings ..... Make Analog input, Pulse, Logic and Calculation settings. DATA settings .... Make settings related to capturing. TRIGGER settings ..Make settings related to the trigger. ALARM settings..
Page 169 Chapter 3 Settings and Measurement File operation Downloading multiple files Delete multiple files Folder/file display ..By double-clicking the folder, you can display the files in the folder. Double-click the file to download the file. Download .......By right-clicking the file/folder and selecting "Download", you can download the file. If you select a folder, all files in the folder are downloaded.
Page 170 Chapter 3 Settings and Measurement List of Error Codes If an error code is displayed on the GL860, please handle errors in reference to the table below. Error code Description –1 Please contact us. Please contact us. File not found. The operation target is not a folder.
Page 171 Chapter 4 Example of Use This chapter provides simple examples of how to use the GL860. SECTION IN THIS CHAPTER Capturing procedure Replay procedure Other functions...
Page 172 Chapter 4 Example of Use Capturing procedure We briefly describe the preparation, setup and capturing procedures for data capturing. Here we take voltage and temperature measurements as an example. Item Description Capturing purpose Voltage and temperature measurement of a target object Target measuring point 2 points Thermocouple...
Page 173 Chapter 4 Example of Use 2. Settings Only the settings necessary for capturing are made here. Use the default settings (factory settings) for other settings. The basic operation of the setting menu On the menu screen, use the " " keys, "ENTER" key, and "QUIT" key to operate. The current cursor position is displayed in "green".
Page 174 Chapter 4 Example of Use Select the temperature with the " " keys. Press the "ENTER" key to confirm. AMP settings Make input settings for CH1 and CH2. Press the "MENU" key to open the AMP setting screen.
Page 175 Chapter 4 Example of Use <CH1 setting> Move the cursor to the CH1 input and set it to "DC". Move the cursor to the CH1 range and set it to "1V". CH2 settings Move the cursor to the CH2 input and set it to "TEMP". Move the cursor to the CH2 sensor and set it to "TC-T".
Page 176 Chapter 4 Example of Use Move the cursor to the CH2 range and set it to “2000℃”. <Other CH settings> Move the cursor to the other CH input and set it to "Off". DATA setting Press the "MENU" key to open the DATA setting screen. Sampling interval setting Move the cursor to the sampling interval and set it to "1s".
Page 177 Chapter 4 Example of Use Data capturing destination setting Set the data capturing destination media, file format, and file naming method. Set the capturing destination to "Internal memory". Set the file format to "GBD". Set the naming method to "Auto". Set the capturing destination folder.
Page 178 Chapter 4 Example of Use The Data saving destination specification dialog opens. In the Data saving destination specification dialog, set the capturing destination of the internal memory (MEM). * In the Data saving destination specification dialog, the folder name is enclosed in < >. Press the "...
Page 179 Chapter 4 Example of Use A "TEST" folder is created. Select the "TEST" folder and press the "ENTER" key. Data is captured in the <TEST> folder of the internal memory (MEM) with an automatic file name. When using the automatic file name function, an additional <DATE> folder is created and the data is saved under it. You can check the available capturing capacity and capturing time at the bottom of the setting screen.
Page 180 Chapter 4 Example of Use 3. Capturing After the capturing settings are complete, start capturing. Start capturing Press the "START/STOP" key. A confirmation message is displayed. Press the "ENTER" key to start capturing. Capturing state When capturing starts, the elapsed time and available capturing time are displayed. Elapsed time Available capturing time 4-10...
Page 181 Chapter 4 Example of Use Replaying during capture When you press the "REVIEW" key during capturing, a replay can be performed during capture. While capturing data, you can replay the data from the beginning of the data to the point at which capturing was performed.
Page 182 Chapter 4 Example of Use Replay procedure 1. Replay procedure We explain the simple procedure for replaying the captured data. The captured data file uses the data captured in the "4.1 Capturing procedure". The captured data files are stored in the "TEST\<date>" folder in the internal memory (MEM). Since the captured data file name was saved with an automatic file name function, a file named "Month/Day/Year-Time.
Page 183 Chapter 4 Example of Use A file selection dialog is displayed. Use the " " keys to move to the desired folder (\MEM\TEST\<date>), and use the " " keys to select the desired file. Use the “ ” key to move to the selected folder. “...
Page 184 Chapter 4 Example of Use Press the "ENTER" to confirm. This completes the replay file settings. Data replay Move the cursor to "OK" using the " " keys. Press the "ENTER" key to play the data. 4-14...
Page 185 Chapter 4 Example of Use 2. Replay screen The data replay screen is described here. 1. Scrollbar 2. Level display 3. Quick settings 6. Cursor 4. Time display (absolute) 5. Time display (relative) Name Description 1. Scrollbar The position and width of the entire waveform range are displayed on the screen. The position of the A/B cursors is also displayed.
Page 186 Chapter 4 Example of Use 3. Finish replaying We describe how to finish the data replay using the data replay screen. Press the "QUIT" key during replay. A confirmation message is displayed. Press the "ENTER" key to finish replaying. When the replay is finished, it will be in free running state. 4-16...
Page 187 Chapter 4 Example of Use Other functions 1. Custom function The custom function is a function that hides the display of the function from the setting menu, etc. by setting the unused functions of the GL860 to OFF. By hiding the display of functions that are not used, the settings can be streamlined and unnecessary setting errors can be prevented.
Page 188 Chapter 4 Example of Use 4. Remote control service cooperation function The GL860 can be linked with the remote control service "G-REMOTE" operated by our company. Waveforms on GL devices can be checked and operated remotely. For details on G-REMOTE and how to apply, please visit our website (http://www.graphteccorp.com/). An optional wireless LAN module is required separately.
Page 189 Chapter 4 Example of Use 7. Inter-CH operation function You can make the calculation result function as an independent CH and measure while comparing it with the original waveform before calculation. Also, each calculation CH can be multiplied by a coefficient. You can add an offset at the end. CALC1 = (a ×...
Page 190 Chapter 4 Example of Use 10. FUNC function When you press the "FUNC" key, what you can do at that time is displayed in the lower right corner of the screen. If you have trouble with the operation, we recommend pressing the "FUNC" key. 11.
Page 191 Chapter 5 Specification This chapter describes the basic specifications for the GL860. SECTION IN THIS CHAPTER Standard Specifications Function Specifications Accessories/Optional Accessories External Dimensions...
Page 192 Chapter 5 Specification Standard Specifications Standard Specifications Item Description Number of analog inputs Maximum 200ch available for 1 terminal(20ch/30ch) or extension unit Analog terminal unit type • Standard 20CH screw terminal • Standard 20CH screwless terminal • Standard 30CH screwless terminal •...
Page 193 E-mail function: Send and receive the e-mail Modbus TCP communication: Communication with sequencers via Modbus TCP. Link function with G-REMOTE: Linkage with Graphtec’s G-REMOTE service. USB functions USB drive mode: Transfer and delete the captured data in the internal memory or SD memory card.
Page 194 Chapter 5 Specification B-563/B-563SL Specifications Item Description Number of input Standard 20CH 20 channels (Up to 200 channels when using with the expansion terminal base) channels screw terminal * Between GL860 and terminal and between terminals can be directly connected or with an expansion terminal connection cable (sold separately) Standard 20CH 20 channels (Up to 200 channels when using with the expansion terminal base)
Page 195 Chapter 5 Specification Item Description • Temperature range Temperature Type Resolution Measurement Range range 100℃ F.S. 0.01℃ 0 to 100℃ 500℃ F.S. 0.05℃ 0 to 500℃ 2000℃ F.S. 0.1℃ R: 0 to 1600℃ S: 0 to 1760℃ 500℃ F.S. 0.05℃ 400 to 500℃...
Page 196 Chapter 5 Specification B-563SL-30 Specifications Item Description Number of input channels 30 channels (Up to 200 channels when using with the expansion terminal base) * Between GL860 and terminal and between terminals can be directly connected or with an expansion terminal connection cable (sold separately) Input terminal type Screwless terminal Input method...
Page 197 Chapter 5 Specification Item Description • Temperature range Temperature Type Resolution Measurement Range range 100℃ F.S. 0.01℃ 0 to 100℃ 500℃ F.S. 0.05℃ 0 to 500℃ 2000℃ F.S. 0.1℃ R : 0 to 1600℃ S : 0 to 1760℃ 500℃ F.S. 0.05℃...
Page 198 Chapter 5 Specification B-565 Specifications Item Description Number of input channels 20 channels (Up to 200 channels when using with the expansion terminal base) * Between GL860 and terminal and between terminals can be directly connected or with an expansion terminal connection cable (sold separately) Input terminal type M3 screw-type terminals (Rectangular flat washer) Input method...
Page 199 Chapter 5 Specification Item Description • Temperature range Temperature Type Resolution Measurement Range range 100℃ F.S. 0.01℃ 0 to 100℃ 500℃ F.S. 0.05℃ 0 to 500℃ 2000℃ F.S. 0.1℃ R : 0 to 1600℃ S : 0 to 1760℃ 500℃ F.S. 0.05℃...
Page 200 Chapter 5 Specification Function Specifications Function Specifications Item Description Display screen Waveform + Digital screen, All Waveform screen, Digital + Calculation Display screen, Expanded digital screen, Alarm history screen * Can be switched using the dedicated key. (toggle operation) * For the Expanded Digital screen, the number of channels and the display channel must be specified. * The waveform is not rewritten due to the change of the TIME / DIV.
Page 201 Chapter 5 Specification Item Description Alarm judgment modes Detection method: Level, Edge Analog channel judgment mode: H ( ), L ( ), Window In, Window Out Logic channel judgment mode: H ( ), L ( Pulse channel judgment mode: H ( ), L ( ), Window In, Window Out Calculation channel judgment mode: H (...
Page 202 Chapter 5 Specification Accessories/Optional Accessories Control Software Item Description Compatible operating system Windows 11 / Windows 10 Function Main unit control, real-time data capture, data conversion Number of groups 4 groups MAX Number of CHs per 1 group Up to the number of connected modules Maximum number of channels 1000 ch maximum Settings...
Page 203 Chapter 5 Specification Battery Pack B-573 (Option) Item Description Capacity 7.2V/2875mAh Battery type Lithium secondary battery Running time Up to two packs can be mounted <When LCD is ON> Battery pack x 1 (brightness MAX): approx. 3 hours Battery pack x 2 (brightness MIN): approx. 6 hours <When LCD is OFF>...
Page 204 Chapter 5 Specification List of Options Item Model Description Input/output cable for GL B-513 2 m long (no clip on end of cable) DC drive cable B-514 2 m long (no clip on end of cable) Humidity sensor * B-530 3 m long (with power plug) Standard 20CH screw terminal B-563...
Page 205 Chapter 5 Specification External Dimensions GL860 Standard 20CH screw terminal (B-563) 52.5 2-M4 L5 Unit: mm Dimension precision: ± 3 mm Terminals 7.62 Unit: mm Dimension precision: ± 0.5 mm 5-15...
Page 206 Chapter 5 Specification GL860 Standard 20CH screwless terminal (B-563SL) 52.5 2-M4 L5 Unit: mm Dimension precision: ± 3 mm 5-16...
Page 207 Chapter 5 Specification GL860 Standard 30CH screwless terminal (B-563SL-30) 52.5 2-M4 L5 Unit: mm Dimension precision: ± 3 mm 5-17...
Page 208 Chapter 5 Specification GL860 Withstand high-voltage high-precision terminal (B-565)) 2-M4 L5 Unit: mm Dimension precision: 3 mm Terminals 7.62 Unit: mm Dimension precision: ± 0.5 mm 5-18...
Page 209 Specifications are subject to change without notice. GL860 User's Manual GL860-UM-151 July 31, 2024 1st edition-02 GRAPHTEC CORPORATION...

GRAPHTEC miid LOGGER GL860 User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for GRAPHTEC miid LOGGER GL860

Summary of Contents for GRAPHTEC miid LOGGER GL860
