CHAPTER 3 Settings and Measurement
Digital display
The digital display is seen on the right side in the "Waveform + Digital display".
The digital display has the following functions.
· See the measured value with a digital value.
· Show CH where the alarm occurred.
· Sets active CH.
· Performs simple setting of SPAN, POSITION and TRACE.
· Operates Quick setting.
The CH where the input is set to Off does not display on the waveform .
3-32
Digital display
Active CH
Quick setting
