CHAPTER 3 Settings and Measurement
When "Always select" is set, items marked with "
the [FUNC] key.
Use the the
Press the [ENTER] key to perform the content you select.
When pressing the [FUNC] key, the
contents that can be executed at
that point are displayed.
(6)-9 Date/Time
This is the setting related to the device clock.
The internal clock (date and time) of the device can be manually set. Alternatively, if the Network Time
setting is used, the clock can be automatically adjusted via the NTP network. Refer to the next section,
"Network Time Setting" for details.
Network time
The device has a function to synchronize with time of clock server via Ethernet.
Using this function, set the Network time.
Setting
(1) Internet Time
(2) NTP Server
(3) Time Zone
(4) Synchronized Time
(5) Adjust Mode
(6) Connection Test
Synchronization is not performed if the time difference with the time server is 500 ms or less.
3-116
keys to select the item you want to perform.
(1)
(2)
(3)
(4)
(5)
(6)
Set whether to use this function or not.
Off: This function is not used. Time adjustment is not performed.
On: Use this function to adjust the time.
Enter the domain name (or IP address) of the time server (NTP server) to be used.
Set the time zone in the area where this device is used. (Japan: +09 00)
* This setting is the same as the time zone setting of SMTP server setting and POP3 server
setting.
Set the time to synchronize with the server.
When the set time comes, the time synchronization operation is performed by the method
set in the synchronous mode.
Set the method to synchronize to the time server.
Immediately: When the synchronization time comes, this device is immediately adjusted to
the time of the time server.
Slowly: Even if the synchronization time comes, this device is not synchronized immediately.
This device gradually synchronizes with the time of the time server.
The adjustment is approx. 43 seconds per day. (Adjustment of approx.10 ms in 20 seconds.)
Perform a connection test to the time server (NTP server).
" are displayed according to the status when pressing
Description
