(2)-13 Backup setting
This device has a function to periodically back up recorded data.
(Refer to the figure below.)
Measurement input
Measurement input
Setting
(1) Backup intervals
(2) Backup Destination
(3) Save folder
If ring capture is On, the backup function is not available .
When set to the CSV file format, the sampling interval is from 10 ms.
To replace the backup destination media, be sure to execute the Remove/Replace in the File menu before
replacing .
GL2000
Auto backup to internal memory
Auto backup to internal memory
(1)
(2)
(3)
Set the interval to back up the captured data.
Off, 1, 2, 6, 12, 24 hours
Set the backup destination of the captured data.
Internal memory
SD card
USB memory
* Capturing destination and backup destination cannot be the same.
* When SD card or USB memory is selected as backup destination, SD card and USB memory
can be replaced. For details, refer to "3.5 Setting Menus" - "7. File menu".
Set the folder to save the backup file.
* This is the folder of the drive specified as the save destination.
Example) \GRAPHTEC\¥20171001
CHAPTER 3 Settings and Measurement
Auto backup to SD memory card
Auto backup to SD memory card
or USB memory
or USB memory
Description
: The data is backed up to the internal memory of the device.
: The data is backed up to the SD card.
: The data is backed up to the USB memory.
3-81
