CHAPTER 3 Settings and Measurement
(2) Capturing
Elapsed time
Capture destination and file name
The captured data is saved in the Internal RAM, internal memory, SD card or USB memory during data
capture.
You can not use the [MENU] key to change the setting.
Operations available during capture
SPAN/TRACE/POSITION change
Screen display mode switch
Replay while capturing
Save to device
Setting check
Time axis change
(3) Data replay during capturing
The captured data while capturing can be replayed by pressing the [REVIEW] key.
Use the Direction keys (
Operations available during capturing
Cursor movement
Save to device
Screen copy
Time axis change
•
During ring capturing, the replay cannot be performed while capturing .
•
During relay capturing, the data cannot be saved to a device .
•
During relay capturing, the replay cannot be performed before the file is switched while capturing.
3-54
The remaining capacity of SD card
(Remaining time more than 99999 hours is
displayed as "++++:++:++" .)
Displays the voltage at a point
indicated by Cursor A or B or the
selected cursor .
Displays the measurement time at a
point indicated by Cursor A or B or the
selected cursor .
) to move the cursor and captured data to check digital values.
Change the settings with the [SPAN/TRACE/POSITION] key.
Change the screen mode with the [DISPLAY] key.
Replay the data captured while capturing
Save to the device with the [FILE] key during data capture.
Display the setting information with the [MENU] key.
Change the time axis with the [TIME/DIV] key.
The [CURSOR] key is used to switch between cursors A and B.
,
The
or
keys are used to move the cursors.
Recording save can be performed from the [FILE] menu.
(The data up to the present or between the cursors can be saved in a
separate file during data capture.)
Copy the screen with the [FILE] key.
Change the time axis with the [TIME/DIV] key.
