Internal RAM

Item
Memory capacity
Memory contents
Sampling interval
Capturing settings
Pre-trigger
Auto-save function
Memory division

Internal memory

Item
Memory capacity
Memory contents
Sampling interval

USB Memory slot

Item
Memory capacity
Memory contents
Sampling interval

SD card

Item
Memory capacity
Memory contents
Sampling interval
4MW/CH volatile memory
Measured data
1, 2, 5, 10, 20, 50, 100, 200, 500 μs
1, 2, 5, 10, 20, 50, 100, 200, 500 ms
1, 2, 5, 10, 20, 30s, 1min, External
Set the number of capturing points
Setting range: 10 to 4000000 points
Input increment: 1 point increment
1 to 4000000 points (Points designation and Time display available)
ON/OFF setting
ON: Auto save to internal memory or USB memory
OFF: Only temporary save in Internal RAM (When the power is turned off, data is erased.
Settable from 4MW x 1, 2MW x 2, 1MW x 4, 0.5MW x 8 divisions.
(Overwrite ON/OFF setting available)
Approx. 4GByte Flash memory
* Up to 4GB for 1 file
Setting condition for this device Measured data, Screen bitmap
Fastest 1 ms/4CH (when using GBD/CSV)
1, 2, 5, 10, 20, 50, 100, 200, 500 ms
1, 2, 5, 10, 20, 30s, 1min, External
No limit (however, up to 4GB for 1 file)
Setting condition for this device Measured data, Screen bitmap
Fastest 1 ms/4CH (when using GBD/CSV)
1, 2, 5, 10, 20, 50, 100, 200, 500 ms
1, 2, 5, 10, 20, 30s, 1min, External
SDHC-compatible, up to 32GByte memory can be used.
* Up to 4GB for 1 file
Setting condition for this device Measured data, Screen bitmap
Fastest 1 ms/4CH (when using GBD/CSV)
1, 2, 5, 10, 20, 50, 100, 200, 500 ms
1, 2, 5, 10, 20, 30s, 1min, External
Description
Description
Description
Description
CHAPTER 4 Specification
4-3
