(7)-10 Character string enter tool
The tool is used to enter the character string such as folder name, file name, annotation character string,
and unit of EU (scaling), etc.
(1)
(2)
Display Item
(1) Character string
selection cursor
(2) Input selection cursor
(3) Character string entry
field
(4) Operation selection
(5) Character selection
< Moving character string cursor >
(1) Use the
and
< Operation selection (selection of character type) >
(1) Press the
key several times to move the enter selection cursor to the operation selection line.
(2) Use the
and
keys to select the operation (character type).
(3)
(4)
(5)
Operation
A
Upper case alphabet mode
a
Lower case alphabet mode
0
Numeric mode
Half-width Kana mode
+
Symbol mode
One character delete
One character insert
User
User defined character string
mode
OK
Confirm
Input character of each mode
keys to move the cursor.
key
CHAPTER 3 Settings and Measurement
Description
This is the cursor that indicates the position to edit the
character string you enter.
This is the cursor to select the input operation.
An input character string is displayed. The character
string cursor is shown in the character to be edited.
Move the input selection cursor, select, insert, delete and
confirm the type of characters you enter.
This mode is for entering upper case alphabets.
This mode is for entering lower case alphabets.
This mode is for entering numbers.
This mode is for entering half-width Kana. (only available
when Japanese setting is used)
This mode is for entering symbols.
One character on the character string selection cursor is
deleted.
One character space is inserted on the character string
selection cursor.
Enter the user defined character string.
Confirm the edited character string and close the tool.
Move the input selection cursor and select the input
character.
3-127
