LAN Connection
(1) This device conforms to the EMC directive when the core is attached to the LAN cable.
When connecting to a PC with a LAN cable, please attach the supplied core to the LAN cable.
For the attaching method of the core, refer to the explanation of connection using USB.
Please use the LAN cable of 30 m or less.
Use the LAN Interface to connect this device to a PC.
LAN cable
Cable Types
• Use a Cross cable to connect directly to a PC without using a hub.
PC
• Use a straight cable when using a hub.
GL2000
PC
GL2000
CHAPTER 2 Checks and Preparation
GL2000
