Chapter 2: External Connectors Pinout Description
Mic-In Connector
Connector number: 3
Pin
Definition
1
MIC1-CR
3
NC
5
AGND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
MIC1_JD
4
MIC1-CL
6
AGND
Line-Out Connector
Connector number: 4
Pin
Definition
1
FRONT_RI
3
NC
5
AGND
21
Pin
Definition
2
FRONT_JD
4
FRONT_LI
6
AGND
VTC 1031 and nROK 1031 Series User Manual
