Chapter 3: Jumpers and Connectors
CAN Terminator Resistor Selection Switch
Connector size: 2 x 2 = 4-pin switch
Connector location: SW7
1
4
O
N
2
3
Pin
1 ON 2 ON
CAN Terminator Resistor (Default)
1 OFF 2 OFF
CAN None Terminator Resistor
