Chapter 2: External Connectors Pinout Description
Mic-in Connector
Connector Number: 9
Pin
Definition
1
MIC1_R
3
NC
5
GND
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
MIC_JD
4
MIC1_L
6
GND
Line-out2 Connector
Connector Number: 10
Pin
Definition
1
SURR OUT_R
3
NC
5
GND
17
Pin
Definition
2
SURR_JD
4
SURR OUT_L
6
GND
VTC 6222 and nROK 6222 User Manual
