Chapter 2: Jumpers and Connectors
Line-in Connector
Connector type: 1x4 4-pin header, 2.0mm pitch
Connector location: JP3
1
4
Pin
Definition
1
FLIN_L
2
JD
3
GND
4
FLIN_R
Copyright © 2019 NEXCOM International Co., Ltd. All Rights Reserved.
Mic-in Connector
Connector type: 1x4 4-pin header, 2.0mm pitch
Connector location: JP4
1
4
Pin
Definition
1
MIC1_L3
2
NC
3
MIC_GND
4
MIC1_R3
21
NISE 105U User Manual
