Chapter 3: Jumpers and Connectors
SATA Connector
Connector location: SATA1
P15
S1
Pin
Definition
P1
NC
P3
NC
P5
GND
P7
SATA_PWR0
P9
SATA_PWR0
P11
NC
P13
NC
P15
NC
S1
GND
S3
SATA_TXN0
S5
SATA_RXN0
S7
GND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
P2
NC
P4
GND
P6
GND
P8
SATA_PWR0
P10
GND
P12
SATA_PCIE_DETP0
P14
NC
S2
SATA_TXP0
S4
GND
S6
SATA_RXP0
56
