Chapter 2: External Connectors Pinout Description

Power Button

Connector number: 1
•
Before OS: Blue Blinking
•
Enter OS: Blue Stay on
• Power Fail: Red Stay on
•
Red color (Blinking) when input power is 6~9VDC
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.

LED Indicators

Connector number: 2
LAN1 WLAN WWAN
LAN2 Program LED Storage
LED Color
LAN1/LAN2 Green
WLAN Yellow
Program LED Red
WWAN Yellow
Storage Yellow
20
Status Description
Stay On LAN active
Blinking LAN access
Stay On WLAN active
Stay On Programmable LED
Stay On WWAN active
Blinking Storage access
