Chapter 3: Jumpers and Connectors
M.2 2230 Key E Socket (USB 2.0, PCIe 3.0x2)
Connector location: CN16, WLAN
75 74
1
2
Pin
Definition
1
GND
3
USB_P
5
USB_N
7
GND
9
NC
11
NC
13
NC
15
NC
17
NC
19
NC
21
NC
23
NC
33
GND
35
PCIE_TXP2
37
PCIE_TXN2
39
GND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Screw hole for 2330 module
Pin
Definition
2
VCC3
4
VCC3
6
WLAN1_LED#
8
NC
10
NC
12
NC
14
NC
16
WLAN2_LED#
18
GND
20
NC
22
NC
24
NC
34
NC
36
NC
38
NC
40
NC
Pin
Definition
41
PCIE_RXP0
43
PCIE_RXN0
45
GND
47
PCIE_CLKP0
49
PCIE_CLKN0
51
GND
53
CLKREQ0#
55
PEWAKE#
57
GND
59
PCIE_TXP3
61
PCIE_TXN3
63
GND
65
PCIE_RXP1
67
PCIE_RXN1
69
GND
71
PCIE_CLKP1
73
PCIE_CLKN1
75
GND
47
Pin
Definition
42
NC
44
NC
46
NC
48
NC
50
SUSCLK
52
RST0#
54
BT_DIS#
56
WIFI_DIS#
58
SM1_D
60
SM1_C
62
I2C_ALERT#
64
NC
66
RST1#
68
CLKREQ1#
70
NC
72
VCC3
74
VCC3
VTC 1031 and nROK 1031 Series User Manual
