Appendix G: Power Consumption
Item Device
Idle state
Full state (Burn-In)
S0 state
1
Full state + load
Full state + loading + PoE
(VTC 1031-C2 / nROK 1031-C2)
2 S3 state Full state Sleep mode
3 IGN OFF (S5) Full state IGNITION OFF
*WWAN: Enable wakeup function of WWAN module
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Test Case
12V
24V
36V
12V
24V
36V
12V
24V
36V
12V
24V
36V
12V
12V wake up WWAN
24V
24V wake up WWAN
36V
36V wake up WWAN
12V
12V wake up WWAN
24V
24V wake up WWAN
36V
36V wake up WWAN
107
Average
Current(A) Watt(W) Current(A)
1.59 19.08 2.07
0.79 18.96 1.06
0.59 21.24 0.73
2.82 33.84 3.01
1.51 36.24 1.62
1.09 39.24 1.22
3.97 47.64 4.24
2.04 48.96 2.19
1.52 54.72 1.63
8.86 106.32 9.14
4.32 103.68 4.53
3.03 109.08 3.14
0.4 4.8 N/A
0.42 5.04 N/A
0.21 5.04 N/A
0.23 5.52 N/A
0.2 7.2 N/A
0.22 7.92 N/A
0.009 0.108 N/A
0.05 0.6 N/A
0.008 0.192 N/A
0.04 0.96 N/A
0.01 0.36 N/A
0.03 1.08 N/A
Maximus
Watt(W)
24.84
25.44
26.28
36.12
38.88
43.92
50.88
52.56
58.68
109.68
108.72
113.04
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
