Controlling the Acquisition of Data
Disabled - FastSave is selected: This appears when acquisition is paused. It means that the display
update is disabled until FastSave is disabled. FastSave acquisition will not begin until you select Run.
Saving X of XX - FastSave is active and saving files. This appears only while FastSave is active.
Done saving - restart with Stop, then Run .. More - Displayed when the specified number of files
have been saved. FastSave can be restarted by selecting Run to begin a new set of acquisitions.

FastSave Tab

Use FastSave tab is used to configure and initiate
Setting
FastSave acquisition data
Format
Base file name
Location
Max files saved per Run
xxx
SPECMON3 & SPECMON6 Printable Help
FastSave (see page 375)
Description
Enables/disables FastSave acquisitions. If acquisitions are running, selecting the
FastSave acquisition data checkbox immediately begins saving acquisition data to files.
If the instrument is paused, FastSave acquisitions will not begin until you select Run.
Specifies the file format of the FastSave acquisition data files. Files can be saved in
TIQ or MAT format.
Specifies the base name for acquisition data filenames. When acquisition data files are
saved, a 24-character timestamp is appended to the base file name. The maximum base
file name length cannot exceed 232 characters.
Specifies the directory location where files will be saved. Files can be saved on the
local hard drive, a network location or even a USB- connected drive. However, due to
the time required to transfer files across a network or by USB, the local hard drive is
the only recommended location.
Specifies the number of files to be saved each time a FastSave acquisition is started.
The number of files that can be saved is limited only by the storage space available.
Each saved acquisition file uses about 3.3 MB of space.
FastSave Tab
acquisitions.
