Pulsed RF
Changing the Pulse Trace Display Settings (see page 255)

Pulse Trace Settings

Menu Bar: Setup > Settings
Front Panel: Settings
Application Toolbar:
The Setup settings for the Pulse Trace display are shown in the following table.
Settings tab
Params (see page 257)
Define (see page 259)
Levels (see page 264)
Freq Estimation (see
page 264)
Scale (see page 266)
Prefs (see page 267)
xxx

Pulse Statistics Display

The Pulse Statistics view displays a plot of a pulse measurement's values for every pulse in the analysis
period. For example, the Pulse Statistics display will show the rise time measurement for each of 30
pulses, with rise time on the Y axis and pulse number on the X axis. Alternatively, the Statistics Display
can show an FFT trace for the values of a measurement over all the pulses analyzed. Numeric readouts of
Max, Min, and Average in this display summarize results for the selected pulse measurement.
SPECMON3 & SPECMON6 Printable Help
Description
Specifies several parameters that control how pulses are counted and defined.
Specifies parameters that control where measurements are taken on a pulse.
Specifies parameters that control the method and levels used to calculate some pulse
values.
Specifies the reference used for computing frequency error.
Specifies the vertical and horizontal scale settings.
Specifies whether on not certain display elements are shown.
Pulse Trace Settings
255
