Analyzing Data

Analysis Settings

Menu Bar: Setup > Analysis
Application Toolbar:
The Analysis control panel provides access to settings that are used by all displays. These settings affect
only post processing and they do not control hardware settings.
Setting
Analysis Time (see page 349)
Spectrum Time (see page 351)
Frequency (see page 351)
Units (see page 355)
xxx

Analysis Time Tab

The Analysis Time tab contains parameters that define the portion of the acquisition record that is used
for analysis.
SPECMON3 & SPECMON6 Printable Help
Description
Specifies the length of time to use in measurements.
Specifies whether the Spectrum Analysis display uses the same Analysis Time
parameters as all the other displays or if it uses a different Offset and Length.
Specifies the measurement frequency (center frequency).
Specifies the Power units for all displays.
Analysis Settings
