Orientation
Ref Setting
number
1 Displays
2 Markers
3 Settings
4 Trigger
5 Acquire
6 Analysis
7 Frequency
8 Reference Level
9 Amplitude
10 Replay
11 Run
12 Check mark indicator
13 Recall
14
Save
15 Preset
xxx
18
Description
Opens the Select Displays dialog box so that you can select measurement
displays.
Opens or closes the Marker toolbar at the bottom of the window.
Opens the Settings control panel for the selected display. Each display has
its own control panel.
Opens the Trigger control panel so that you can define the trigger settings.
Opens the Acquire control panel so that you can define the acquisition settings.
Opens the Analysis control panel so that you can define the analysis settings
such as frequency, analysis time, and units.
Displays the frequency at which measurements are made. For spectrum
displays, this is called "Center Frequency". To change the value, click the
text and use the front panel knob to dial in a frequency. You can also enter
a frequency with the front panel keypad or use the front panel up and down
buttons.
Displays the reference level. To change the value, click the text and enter a
number from the keypad or use the front panel up and down buttons.
Opens the Amplitude control panel so that you can define the Reference Level,
configure internal attenuation, and enable/disable the (optional) Preamplifier.
Runs a new measurement cycle on the last acquisition data record using any
new settings.
Starts and stops data acquisitions. When the instrument is acquiring data, the
button label has green lettering. When stopped, the label has black lettering.
You can specify the run conditions in the Run menu. For example, if you
select Single Sequence in the Run menu, when you click the Run button,
the instrument will run a single measurement cycle and stop. If you select
Continuous, the instrument will run continuously until you stop the acquisitions.
The check mark indicator in the upper, left-hand corner of the display indicates
the display for which the acquisition hardware is optimized.
Displays the Open window in order to recall setup files, acquisition data files,
or trace files.
Opens the Save As dialog in order to save setup files, pictures (screen
captures), acquisition data files, or export measurement settings or acquisition
data.
Recalls the Preset (Main) (see page 402)
Elements of the Display
preset.
