RF Measurements
Front Panel: Settings
Application Toolbar:
The control panel tabs for the Phase Noise display are shown in the following table.
Settings tab
Frequency (see page 351)
Parameters (see page 189)
Traces (see page 220)
Scale (see page 224)
Prefs (see page 225)
xxx
Restore defaults.
SPECMON3 & SPECMON6 Printable Help
Description
Specify Measurement BW and Integration BW. Enable carrier frequency tracking and
specify the Carrier threshold level.
Specifies the Optimization method.
Specifies trace parameters such as detection method and whether smoothing in enabled.
Traces can also be saved and loaded for reference from this tab.
Specify vertical and horizontal scale settings.
Specify appearance features of the graph area.
Sets the Phase Noise parameters to their default values.
Phase Noise Settings
187
