Analog Modulation
3. Check the Show Recalled Trace check box.
4. Verify that the Show check box is selected.
Scale Tab
The Scale tab allows you to change the vertical and horizontal scale settings. Changing the scale settings
changes how the trace appears on the display but does not change control settings such as Measurement
Frequency. In effect, these controls operate like pan and zoom controls.
Setting
Vertical
Scale
Position
Autoscale
Horizontal
Scale
Position
Autoscale
xxx
SPECMON3 & SPECMON6 Printable Help
Description
Changes the range shown between the top and bottom of the graph.
Adjusts the frequency shown at the center of the graph.
Resets the Position so that the entire trace fits within the graph.
Changes the range shown between the left and right sides of the graph.
Adjusts the position of the acquisition record shown at the left edge of the graph.
Resets the Scale and Position settings to provide the optimum display.
Scale Tab
