GP Digital Modulation
Application Toolbar:
The settings for the Eye Diagram display are shown in the following table.
NOTE. You might be able to save time configuring the Eye Diagram display by pressing the Standard
Settings button from the Settings control panel. This allows you to select a preset optimized for a standard
from the Select Standard dialog box. See
Settings tab
Modulation Params (see
page 309)
Freq & BW (see page 313)
Advanced Params (see
page 316)
Find (see page 319)
Analysis Time (see page 319)
Trace (see page 321)
Scale (see page 323)
Prefs (see page 323)
xxx

Frequency Deviation vs Time Display

To show a Frequency Deviation vs Time display:
1. Press the Displays button or select Setup > Displays. This shows the Select Displays dialog box.
2. From the Folders box, select Frequency Deviation vs Time.
3. Double-click the Frequency Deviation vs Time icon in the Available Displays box. This adds the
Frequency Deviation vs Time icon to the Selected displays box.
4. Click the OK button. This displays the Frequency Deviation vs Time view.
292
Standard Settings Button. (see page 308)
Description
Specifies the type of modulation used for the input signal and other parameters.
Specifies settings for frequency error, measurement BW and Frequency Deviation. Each
of these settings is set internally when set to Auto. Alternatively, you can specify values
appropriate for specific measurement needs.
Specifies additional parameters.
Used to set parameters for finding a burst within the data record and for entering a
Synch word.
Contains parameters that define the portion of the acquisition record that is used for
analysis. Also allows you to specify the Units (Seconds or Symbols) for the GP Digital
Modulation displays.
Allows you to set the trace display characteristics.
Specifies the horizontal and vertical scale settings.
Enables you to set characteristics of the measurement display.
Frequency Deviation vs Time Display
