Amplitude Corrections
3. To edit values in the table:
a. To edit an existing value, double-click on the cell you want to edit.
b. To add a new point to the table, click on Add Point. Edit the values as required.
c. Click Apply if you want to test your table without closing the editor (the table must be enabled
with the check box in the control panel and measurements must already be running).
To specify a frequency multiplier, you can type K, M, or G.
4. To delete a point from the table, select the point to be removed, and click Delete.
5. Select the Frequency Interpolation method:
Select Linear when the frequency scale of the spectrum or spurious measurements are linear.
Select Log when the frequency scale of the spectrum is logarithmic.
6. When you have entered all the necessary values, click Save As (to save the table in a file) or click OK.
7. From the Save As dialog, name the file and save it in the desired location.
External loss tables are saved in CSV (Comma Separated Value) format.
Loading an External Loss Table
To load an external loss table file:
1. Click Edit to display the Table Editor.
2. Click Load to display the Open dialog box.
3. Navigate to the location of the desired file, select it and click Open.
4. Click OK.
