Orientation
Reference Item
11 Run/Stop
12 Peak (Markers
section)
13 Select (Markers
section)
14
Define (Markers
section)
15 Control knob
16 Arrow keys
17 Increment/decre-
ment keys
18
Delete, (Markers
section)
19 Add, (Markers
section)
20 Replay
21
Single
xxx
SPECMON3 & SPECMON6 Printable Help
Function
Starts and stops acquisitions.
Moves the active marker to the
maximum peak of the trace in the
selected display. If markers are
turned off, the marker reference (MR)
will appear at the maximum peak.
Selects the next marker. If markers
are turned off, the MR marker (marker
reference) will appear.
Opens the Markers control panel.
If markers are turned off, the MR
marker (reference) will appear.
Changes values in numeric and list
controls. Pressing the knob (clicking
it) is the same as pressing the Enter
key on a keyboard.
Move the Markers. The Up arrow
moves the selected marker to the
next highest peak. The down arrow
moves the selected marker to the
next lower peak value. The right and
left arrows move the selected marker
to the next peak.
Increments or decrements the
selected value
Deletes the selected marker
Add a marker to the selected trace
Replays the current acquisition record
Sets the Run mode to Single
Sequence
Front-Panel Controls
Menu Equivalent
Run > Start Run > Stop
Markers > Peak
11
