Ofdm Symbol Table Settings; Ofdm Analysis Shared Measurement Settings - Tektronix SPECMON3 Manual

OFDM Analysis
(cont.)
Item
3
4
xxx

OFDM Symbol Table Settings

Front Panel: Settings
Application Toolbar:
The settings for the OFDM Symbol Table display are shown in the following table.
Settings tab
Modulation Params (see
page 244)
Advanced Params (see
page 245)
Data Range (see page 246)
Analysis Time (see page 246)
Prefs (see page 250)
xxx

OFDM Analysis Shared Measurement Settings

Front Panel: Settings
Application Toolbar:
The control panel tabs in this section are shared between the displays in the OFDM Analysis folder (Setup
> Displays). Some tabs are shared by all the displays, some tabs are shared by only a couple of displays.
The settings available on some tabs change depending on the selected display.
SPECMON3 & SPECMON6 Printable Help
Description
Subcarrier data values.
Marker readout when markers are enabled.
Description
Specifies the type of modulation used for the input signal and other parameters.
Specifies parameters used by the instrument to analyze the input signal.
Specifies which symbols and subcarriers of the signal to display.
Specifies parameters that define the portion of the acquisition record that is used for
analysis. Also allows you to specify the Units (Symbols or Seconds) for OFDM Analysis
displays.
Specifies the units of the display and whether elements of the graphs are displayed.
OFDM Symbol Table Settings
243
