MCPR Settings

Menu Bar: Setup > Settings
Front Panel / Application Toolbar: Settings
The Setup control panel tabs for MCPR (Multiple Carrier Power Ratio) are:
Settings tab
Freq & RBW (see page 160)
Measurement Params (see
page 161)
Channels (see page 163)
Scale (see page 224)
Prefs (see page 225)
xxx
Restore defaults.
SPECMON3 & SPECMON6 Printable Help
Description
Specify the frequency and resolution bandwidth used for the MCPR measurements.
Specifies parameters controlling how the MCPR measurement is made.
Specifies the parameters of the channels to be measured.
Specifies the vertical and horizontal scale and offset values.
Specifies whether or not certain display elements are shown.
Sets parameters for a 4-carrier WCDMA measurement.
