Search (Limits Testing)

The Search Tool (Limits Testing)

You can specify pass/fail conditions for the Spectrum, Spurious, Frequency Settling Time and Phase
Settling Time displays. When these conditions are met, the instrument can perform actions such as
stopping acquisitions or saving data.

Search (Limits Testing) Settings

Menu Bar: Tools > Search
Selecting Search displays the Search control panel. These settings define search parameters and specify
actions to be performed when the search condition is met.
Setting
Enable Search
Define (see page 343)
Actions (see page 347)
xxx
Define Tab (Search)
The Define tab sets the parameters for a search. From this tab, you specify which trace to search and what
kind of violation to search for.
SPECMON3 & SPECMON6 Printable Help
Description
Select to perform a search.
Specifies which result to search and what to search for.
Specifies the action to take when the search condition is met.
The Search Tool (Limits Testing)
