Interface Connectors and Switches

007-4304-003
• Indicators — Each canister has indicators showing component status. See
"Checking the Drive Enclosure Indicator Lights" on page 92 for details.
Environmental Status Module
Fan Canister
Power Supply Canister
Rear View of the Drive Enclosure
Figure 5-2
Important: An indicator that is glowing amber may indicate a drive enclosure
component failure that needs immediate attention. Run the storage management
software (TPSSM7) to diagnose and repair the problem. For more information on the
indicators, see "Checking the Drive Enclosure Indicator Lights" on page 92.
Figure 5-3 shows the connectors and switches on the rear of the drive enclosure. Table 5-1
describes these items in detail.
Environmental Status Module
GBICs
Caution Label
Interface Connectors and Switches
Fan Canister
GBICs
Power Supply Canister
55009-a
75
