Weights

007-4304-003
13.3 cm
(5.2 in.)
48.0 cm
(19.0 in.)
Figure A-8 Drive Enclosure Dimensions
Ensure that the site's floor can support the total weight of all drive enclosures and
associated equipment. The drive enclosure's total weight depends on the number of
canisters in the enclosure. Table A-13 lists the unit and shipping weights for individual
canisters and the weights of minimum, maximum, and empty drive enclosure
configurations.
Drive Enclosure Specifications
56028
45.0 cm
(17.6 in.)
56.0 cm
(22.0 in.)
0.16 cm
(0.6 in.)
16.6 cm
(6.5 in.)
