2: The Controller Enclosure
Indicator Lights
Control Fan Canister
6
•
Battery canister — One removable canister that contains batteries and battery
charger circuitry.
•
Controller fan canister — One removable canister that contains two cooling fans.
•
Controller canisters — Two removable canisters, each contains one controller.
Front Cover
Front Panel, Cover Removed
Figure 2-1
Front View of the Controller Enclosure
Battery Canister
Controller Canisters
54067-h
007-4304-003
