Figure 1-1 Tp9400 Controller Enclosure, Drive Enclosures, And Blank Panels - Silicon Graphics TP9400 RAID Owner's Manual

1: Introduction to the TP9400
2
Note: JBOD is not supported.
Filler Panels
Drive Enclosures
Controller Enclosure
Drive Enclosures
Figure 1-1 TP9400 Controller Enclosure, Drive Enclosures, and Blank Panels
Following are descriptions of the rack, the controller enclosures, and the drive enclosures
as shown in Figure 1-1.
