0.
O2
™
and OCTANE
™
9-Gigabyte External
Hard Disk Drive Installation Instructions
The 9-gigabyte (GB) external hard disk drive is a 16-bit wide Ultra SCSI hard disk drive
with a 68-pin connector, and is designed to work with both O2 and OCTANE
workstations.
Installing the External Hard Disk Drive
For complete information on installing an external hard disk drive, see the instructions
in the section on installing external SCSI devices in the printed owner's guide for your
particular workstation. The owner's guide includes cable length restrictions and other
important facts about your workstation's SCSI buses.
For the O2 workstation, the information is available in the online O2 Hardware Reference
Guide. From the Toolchest choose Help > Online Books > SGI EndUser > O2 Hardware
Reference Guide.
For the OCTANE and O2 workstations, the information is also available in the online
OCTANE Workstation Owner's Guide and the O2 Hardware Reference Guide in the Technical
Publications Library. Using your Web browser, enter:
http://techpubs.sgi.com/library/ > Catalogs > Hardware Catalogs > OCTANE or O2 >
book title
Document Number 007-3532-002
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Silicon Graphics O2
Summary of Contents for Silicon Graphics O2
- Page 1 SCSI buses. For the O2 workstation, the information is available in the online O2 Hardware Reference Guide. From the Toolchest choose Help > Online Books > SGI EndUser > O2 Hardware Reference Guide. For the OCTANE and O2 workstations, the information is also available in the online OCTANE Workstation Owner’s Guide and the O2 Hardware Reference Guide in the Technical...
- Page 2 ™ and OCTANE ™ 9-Gigabyte External Hard Disk Drive Installation Instructions Using the Correct Cable If this is the first SCSI device attached to the workstation, use the 68-pin to 68-pin SCSI-3 cable and terminator that comes with the device. Using other types of cables or terminators can result in data loss.
- Page 3 Directives listed on the Manufacturer’s Declaration of Conformity. The CE insignia displayed on each device is an indication of conformity to the European requirements. Class B FCC Declaration of Conformance Trade Name Silicon Graphics, Inc. Product External Hard Disk Drive Model Number CMNB019B...
- Page 4 ™ and OCTANE ™ 9-Gigabyte External Hard Disk Drive Installation Instructions particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one or more of the following measures: •...
- Page 5 Silicon Graphics have shielded cables. Shielded cables reduce the possibility of interference with radio, television, and other devices. If you use any cables that are not from Silicon Graphics, make sure they are shielded. Telephone cables do not need to be shielded.
-
Page 6: Product Support
If you are outside North America, contact the Silicon Graphics subsidiary or authorized distributor in your country. © 1998, Silicon Graphics, Inc. All rights reserved. Silicon Graphics is a registered trademark and the Silicon Graphics logo, O2, and OCTANE are trademarks of Silicon Graphics, Inc.
