Controller Enclosure Specifications; Dimensions; Table A-7 Heat Dissipation Requirements - Silicon Graphics TP9400 RAID Owner's Manual

Controller Enclosure Specifications

Dimensions

007-4304-003
Heat Dissipation Requirements
Table A-7
Environment Unit of Measure
Heat Dissipation Configuration A
18 GB drives
36 GB drives
73 GB drives
180 GB drives
Configuration B
18 GB drives
36 GB drives
73 GB drives
180 GB drives
a. 1 controller enclosure, 5 drive enclosures.
b. 2 controller enclosures, 10 drive enclosures.
Below are the dimensions and weights, as well as the wiring, power, environmental, and
airflow requirements for the controller enclosures.
Make sure that the installation site provides a minimum of two feet of space around each
side of the rack to install and service the controller enclosure, and to allow adequate
ventilation during operation. Figure A-6 shows the dimensions for the controller
enclosure and the front cover.

Controller Enclosure Specifications

Requirement
a
1.43 kVA 1442.5 W 4929.5 Btu/hr
1.43 kVA 1442.5 W 4929.5 Btu/hr
1.69 kVA 1697.5 W 5797.5 Btu/hr
1.45 kVA 1439 W 4912 Btu/hr
b
2.87 kVA 2885 W 9855 Btu/hr
2.87 kVA 2885 W 9855 Btu/hr
3.37 kVA 3395 W 11595 Btu/hr
2.90 kVA 2878 W 9824 Btu/hr
153
