Table 6-2 Indicator Lights (Rear) - Silicon Graphics TP9400 RAID Owner's Manual

Component Indicator Light
Environmental Environmental Card
Status Module Fault Indicator
Environmental Card
Power Indicator
In, Out Bypass
Indicators
Overtemp Indicator
ID Conflict Indicator Amber
Fan Canister Fan Fault Indicator
Power Supply Power Supply Fault
Canister Indicator
Power Supply
Power Indicator
a. Always use the storage management software (TPSSM7) to precisely identify a failure.
b. If nothing is connected to the corresponding connector, this fault light is on. If a cable is connected and it is functioning properly, this light is off.
c. This indicates a problem only if a GBIC is plugged into the corresponding connector (see footnote a). Also, more than one Bypass indicator
will be on if the connection fails. Usually, if a GBIC fails, its Bypass indicator will come on, as will the Bypass indicator of the GBIC to which
it is connected.
d. The Overtemp indicator comes on if the internal drive enclosure temperature reaches 40˚ C (104˚ F). See Chapter 6, "Overtemp Condition" for
more information on the overtemp condition.
007-4304-003
Note: The normal operating state of all indicators on the rear panel is green (blinking if
the drives are processing data). If an amber indicator is on, or a green indicator is off, use
the storage management software (TPSSM7) to determine the nature of the fault and the
recovery procedure.
Exception: If the drive Fault indicators are blinking, it means that the storage
management software (TPSSM7) is locating a drive enclosure component. It does not
indicate a failure.
Table 6-2 Indicator Lights (Rear)
Normal
Color Operation
Amber Off
Green On, steady Off
Amber Off
On, steady
d Amber Off
Off
Amber Off
Amber Off
Green On, steady Off
Checking the Drive Enclosure Indicator Lights
Problem
Indicator Condition Indicated
On, steady Environmental card canister failure
No power to drive enclosure; no power to storage
array; overtemp condition; power supply failure
c
On, steady GBIC failure; cable failure; controller enclosure
mini-hub failure
b
On, steady Overtemp condition; fan failure
On, steady Enclosure number is set incorrectly; enclosure
number is in use by another subsystem on the loop
On, steady Fan canister failure; overtemp condition
On, steady Power supply failure; overtemp condition
Power supply off; power supply disconnected;
power supply is seated incorrectly; no power to
drive enclosure; no power to storage array
a
