Controller B
Port 2
Controller A
Port 2
Controller B
Port 1
Controller A
Port 1

In-Band and Out-of-Band Array Management

007-4304-003
Host A
1
2
Switch A
Multi-Switch Connect — 2 Host
Figure 8-12
There are two methods of managing the TP9400. In-band management requires only the
Fibre Channel host interface be present and functional. Out-of-band management
requires Ethernet or serial connections be cabled to each controller.
Connecting the TP9400 to the Hosts
Host B
1
2
Switch B
135
