007-4304-003
Loop A Interface Cable
Drive Group 1
Controller Enclosure
Drive Group 2
(for redundancy)
Loop C Interface Cable
Figure 8-5 Two Drive Groups, Each With Redundant Drive Loops
5. Connect drive Loop D to the controller enclosure (Figure 8-5).
Connecting Drive Cables to the Controller Enclosure
Loop B Interface Cable
Drive Loop A
Drive Loop B
Drive Loop C
Drive Loop D
54051-e
Loop D Interface Cable
127
