A: Specifications and Requirements

Wiring and Power

160
Table A-13 Drive Enclosure Weights
Unit
Drive Enclosure
(18 GB)
Drive Enclosure
(36 GB)
Drive Enclosure
(73 GB)
Drive Enclosure
(181 GB)
Empty Drive Canister
Environmental Card
Canister
Power Supply Canister
Fan Canister
a. Contains four drive canisters, two environmental card canisters, two fan canisters, and two
power supply canisters.
b. Contains 10 drive canisters, two environmental card canisters, two fan canisters, and two
power supply canisters.
c. Drive enclosure weight with all canisters removed.
d. Includes shipping carton and fully configured drive enclosure.
The drive enclosure is a 120/220 VAC, 50/60 Hz unit that meets standard voltage
requirements for domestic and international operation. It uses standard industrial wiring
a b
Minimum Maximum
30.4 kg 38.6 kg
(67.0 lb) (85.0 lb)
29.9 kg 37.2 kg
(66.0 lb) (82.0 lb)
31.3 kg 40.4 kg
(69.0 lb) (89.0 lb)
36.18 kg 42.8 kg
(80.0 lb) (94.0 lb)
1.4 kg
(3.0 lb)
1.8 kg
(4.0 lb)
2.5 kg
(5.4 lb)
1.0 kg
(2.2 lb)
c d
Empty Shipping
12.7 kg 51.3 kg
(28.0 lb) (113.0 lb)
12.7 kg 50.4 kg
(28.0 lb) (111.0 lb)
12.7 kg 53.1 kg
(28.0 lb) (117.0 lb)
12.7 kg 55.4 kg
(28.0 lb) (122.0 lb)
007-4304-003
