007-4304-003
Handle
Captive
Screws
Figure 4-10 Removing and Installing a Fan/Communications Canister
5. Install the new fan/communications canister.
Push the new fan/communications canister all the way into its chassis slot. Use a
flat-blade screwdriver to tighten the three captive screws on the new canister,
securing it into place.
6. Check the Fan/Communications Fault indicator (Figure 4-9 on page 61). The amber
Fault indicator should be off.
• If the Fault indicator turns on — Make sure that the fan/communications
canister is inserted all the way into the chassis and secured in place.
• If the Fault indicator remains on — One or both fans inside the
fan/communications canister might be malfunctioning. Replace the failed
fan/communications canister with a spare, if available. If not, shut down the
Replacing a Failed Fan/Communications Canister
54038
63
