4: Controller Enclosure Component Replacement Procedures
50
Using the proper handling precautions, remove the new controller from the packing
material. Check the shipping invoice and the controller to make sure that it is the
same type as the one you are going to replace.
2. Determine if you must modify the steps in this procedure.
a. Read the kit instructions shipped with the new controller canister as well as all
controller repair and recovery instructions provided with the operating system
and storage management software (TPSSM7).
b. If necessary, modify the remaining steps to meet the system requirements. Kits
often contain the most current servicing information. If the kit instructions
conflict with those in this procedure, use the kit instructions.
3. Remove the front cover (Figure 4-1).
1
Removing the Front Cover of the Controller Enclosure
Figure 4-1
56007
2
007-4304-003
