HIKVISION DS-2TD8166-180ZE2F-V2 User Manual

Thermal bi-spectrum network positioning system
Hide thumbs Also See for DS-2TD8166-180ZE2F-V2:
Table of Contents

Advertisement

Quick Links

Download this manual
Thermal Bi-spectrum
Network Positioning System
User Manual
UD05158B

Advertisement

Table of Contents
loading

Related Manuals for HIKVISION DS-2TD8166-180ZE2F-V2

Summary of Contents for HIKVISION DS-2TD8166-180ZE2F-V2

  • Page 1 Thermal Bi-spectrum Network Positioning System User Manual UD05158B...
  • Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
  • Page 3 User Manual of Thermal Network Positioning system CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER PREVAILS.
  • Page 4 (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements. © Hikvision...
  • Page 5  Improper use or replacement of the battery may result in explosion hazard. Replace with the same or equivalent type only. Dispose of used batteries in conformance with the instructions provided by the battery manufacturer.  Never attempt to disassemble the device. 0504001070316 © Hikvision...

  • Page 6: Table Of Contents

    Setting / Calling a Patrol ..................... 27 One-touch Patrol ......................29 4.4.15 4.4.16 Setting / Calling a Pattern ..................29 Playback ..........................30 Play Back Video Files ...................... 31 4.5.1 Downloading Video Files ....................32 4.5.2 Pictures ..........................33 © Hikvision...
  • Page 7 Configuring Audio Settings ..................92 7.2.3 Configuring ROI Settings .................... 92 PTZ Configuration ....................... 94 Configuring Basic PTZ Parameters ................94 7.3.4 7.3.5 Configuring PTZ Limits ....................96 7.3.6 Configuring Initial Position ..................97 7.3.7 Configuring Park Actions .................... 98 © Hikvision...
  • Page 8 Configuring DPC Settings ..................116 7.4.6 Picture in Picture ....................... 117 Configuring System Settings ................... 118 System Settings ......................118 7.5.1 7.5.2 Maintenance ......................122 7.5.3 Security ........................126 7.5.4 User Management ..................... 128 Appendix ............................133 SADP Software Introduction ......................133 © Hikvision...

  • Page 9: Chapter 1 Overview

    CPU: Intel Pentium IV 3.0 GHz or higher RAM: 1G or higher Display: 1024× 768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.02 and above version, Mozilla Firefox 5 and above version and Google Chrome 18 and above versions. © Hikvision...

  • Page 10: Functions

    This keeps the image from moving too fast on the live view image when there is a large amount of zoom.  Auto Focus The auto focus enables the camera to focus automatically to maintain clear video images.  Day/Night Auto Switch © Hikvision...
  • Page 11 Comparing with the general 2D digital noise reduction, the 3D digital noise reduction function processes the noise between two frames besides processing the noise in one frame. The noise will be much less and the video will be clearer. © Hikvision...

  • Page 12: Chapter 2 Network Connection

    Figure 2-1. Refer to the Figure 2-2 to set the network positioning system over the LAN via a  switch or a router. Network Cable PT Camera Figure 2-1 Connecting Directly © Hikvision...

  • Page 13: Activating The Positioning System

    The default IP address of the positioning system is 192.168.1.64. Figure 2-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED–We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, © Hikvision...
  • Page 14 (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product. And we recommend you reset your password © Hikvision...
  • Page 15 Get the client software from the supplied disk or the official website, and install the software according to the prompts. Follow the steps to activate the camera. Steps: Run the client software and the control panel of the software pops up, as shown in the figure below. © Hikvision...
  • Page 16 Figure 2-7 Device Management Interface Check the device status from the device list, and select an inactive device. Click Activate to pop up the Activation interface. Create a password and input the password in the password field, and confirm the password. © Hikvision...
  • Page 17 Figure 2-9 Modifying the Network Parameters Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Input the password to activate your IP address modification. © Hikvision...

  • Page 18: Setting The Network Positioning System Over The Wan

    Connecting the network positioning system with static IP directly  You can also save the static IP in the positioning system and directly connect it to the internet without using a router. Refer to Section 2.1.2 for detailed IP address configuration of the positioning system. © Hikvision...

  • Page 19: Dynamic Ip Connection

    IP address by ADSL dial-up after the positioning system is connected to a modem. You need to configure the PPPoE parameters of the network positioning system. Refer to Section 7.1.1 Configuring PPPoE Settings for detailed configuration. © Hikvision...
  • Page 20 2. Configure the DDNS settings in the DDNS Settings interface of the network positioning system. Refer to Section 7.1.1 Configuring DDNS Settings for detailed configuration. 3. Visit the positioning system via the applied domain name.  Private Domain Name Resolution © Hikvision...
  • Page 21 2. Access the network positioning system through the LAN with a web browser or the client software. 3. Enable DDNS and select IP Server as the protocol type. Refer to Section 7.1.1 Configuring DDNS Settings for detailed configuration. © Hikvision...

  • Page 22: Chapter 3 Access To The Network Positioning System

    6. Install the plug-in before viewing the live video and operating the positioning system. Please follow the installation prompts to install the plug-in. You may have to close the web browser to install the plug-in. Please reopen the web browser and log in again after installing the plug-in. © Hikvision...

  • Page 23: Accessing By Client Software

    The product CD contains the client software. You can view the live video and manage the positioning system with the client software. Follow the installation prompts to install the client software and WinPcap. The client software configuration interface and live view interface of are shown below. Figure 3-3 iVMS-4200 Control Panel © Hikvision...
  • Page 24 If you use third party VMS software, please contact technical support of our branch  for camera firmware.  For detailed information about client software of our company, please refer to the user manual of the software. This manual mainly introduces accessing to the network positioning system by web browser. © Hikvision...

  • Page 25: Chapter 4 Basic Operations

    MULTICAST: It’s recommended to select the protocol type to MULTICAST when using the Multicast function. HTTP: Allows the same quality as of TCP without setting specific ports for streaming under some network environments.  Play Performance: Set the play performance to Shortest Delay, or Auto. © Hikvision...

  • Page 26: Live View Page

    The live video page allows you to view live video, capture images, realize PTZ control, set/call presets and configure video parameters. Log in the network positioning system to enter the live view page, or you can click on the menu bar of the main page to enter the live view page. © Hikvision...

  • Page 27: Starting Live View

    Configure the image size, stream type, plug-in type, and two-way audio of the live video. 4.3 Starting Live View In the live view window as shown in Figure 4-3, click on the toolbar to start the live view of the positioning system. © Hikvision...
  • Page 28 4:3/16:9/ original/self-adaptive window size.  Click to select from and display live video with the main/ sub/third stream. The main stream is with a relatively high resolution and needs much bandwidth. The default setting of stream type is © Hikvision...

  • Page 29: Operating Ptz Control

     and Section 7.2.1 Configuring Video Settings.  Setting the OSD text on live video in Section 7.4.2 Configuring OSD Settings. 4.4 Operating PTZ Control Purpose: In the live view interface, you can use the PTZ control buttons to control panning, tilting and zooming. © Hikvision...

  • Page 30: Ptz Control Panel

    PTZ Control Panel Click and the positioning system keeps panning, the icon turns into . Click the icon again to stop the positioning system. Click , the lens zooms in, click Zoom out/in , and the lens zooms out. © Hikvision...

  • Page 31: Auxiliary Functions

    Buttons Description Start the selected patrol/pattern. Stop current patrol/pattern. Set the selected preset/patrol. Delete the selected preset/patrol/pattern. Start recording a pattern. Stop recording the pattern. 4.4.2 Auxiliary Functions The Auxiliary functions panel is shown in the figure below: © Hikvision...
  • Page 32 The corresponding position will be moved to the center of the live video and zoomed in. 5. Hold down the left mouse button and drag the mouse to the upper left on the live video. The corresponding position will be moved to the center of the live video and zoomed out. © Hikvision...

  • Page 33: Setting / Calling A Preset

    5. You can click to delete the preset. You can configure up to 256 presets.  Calling a Preset: In the PTZ control panel, select a defined preset from the list and click to call the preset. © Hikvision...
  • Page 34 Night mode (IR cut filter out) Start auto scan Call pattern 1 Start tilt scan Call pattern 2 Start panorama scan Call pattern 3 Call patrol 5 Call pattern 4 Call patrol 6 One-touch Patrol Call patrol 7 Wiper Call patrol 8 © Hikvision...

  • Page 35: Setting / Calling A Patrol

    Steps: 1. In the PTZ control panel, click to enter the patrol settings interface. 2. Select a patrol number from the list and click 3. Click to enter the adding interface of preset, as shown in Figure 4-9. © Hikvision...
  • Page 36 7. Click OK to save all the patrol settings. Calling a Patrol:  In the PTZ control panel, select a defined patrol from the list and click to call the patrol, as shown in Figure 4-10. Figure 4-10 Calling a Preset © Hikvision...

  • Page 37: One-Touch Patrol

    Pattern function varies depending on positioning system models.  Setting a Pattern: Steps: 1. In the PTZ control panel, click to enter the pattern settings interface. 2. Select a pattern number from the list as shown in Figure 4-12. © Hikvision...

  • Page 38: Playback

    When configuring and calling the pattern, proportional pan is valid; the limit stops and  auto flip will be invalid; and the 3D positioning operation is not supported. 4.5 Playback Purpose: This section explains how to view the video files stored in the network disks or memory cards. © Hikvision...

  • Page 39: Play Back Video Files

    Select the date and click Figure 4-14 Search Video Click to play the video files found on this date. The toolbar on the bottom of Playback interface can be used to control playing process. Figure 4-15 Playback Toolbar © Hikvision...

  • Page 40: Downloading Video Files

    Figure 4-16 Set Playback Time Figure 4-17 Progress Bar The different colors of the video on the progress bar stand for the different video types as shown in Figure 4-18. Figure 4-18 Video Types 4.5.2 Downloading Video Files Steps: © Hikvision...

  • Page 41: Pictures

    4.6 Pictures Purpose: This section explains how to view the captured picture files stored in the network disks or the memory cards and download the captured pictures. Steps: Click on the menu bar to enter picture interface. © Hikvision...
  • Page 42 Select the file type of capturing the pictures from the list as timing, alarm, motion, etc. Set the start time and end time. Click Search. The corresponding picture files will be listed. Check the checkbox in front of the files that you need to download. Click to download the files. © Hikvision...

  • Page 43: Chapter 5 System Configuration

    Configuration > Storage > Schedule Settings > Record Schedule Figure 5-1 Recording Schedule Interface 2. Check the checkbox of Enable to enable scheduled recording. 3. To set the advanced settings of the positioning system, click to enter the advanced settings interface. © Hikvision...
  • Page 44 Channel in the Linkage Method of Motion Detection settings interface. For detailed information, please refer to Section Motion Detection.  Record Triggered by Alarm: If you select Alarm, the video will be recorded when the alarm is triggered via the external alarm input channels. Besides configuring © Hikvision...

  • Page 45: Configuring Capture Schedule

    5.1.2 Configuring Capture Schedule Purpose: You can configure the scheduled snapshot and event-triggered snapshot. The captured picture can be stored in the local storage or network storage. Steps: Enter the Snapshot settings interface: Configuration > Storage > Storage Settings > Capture © Hikvision...
  • Page 46 Please refer to Section 7.1.2 Configuring FTP Settings for more details to configure FTP parameters. 2) Check the Enable Timing Snapshot checkbox. 3) Click Edit to set the snapshot schedule. Refer to Section 5.2.1 Configuring Motion Detection. © Hikvision...

  • Page 47: Configuring Net Hdd

    The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. © Hikvision...
  • Page 48 When the initialization completed, the status of disk will become Normal as shown in Figure 5-7. Figure 5-7 View Disk Status  Define the Quota for Record and Pictures 1. Input the quota percentage for picture and for record. 2. Click Save and refresh the browser page to activate the settings. © Hikvision...

  • Page 49: Basic Event Configuration

    Steps: Enter the motion detection setting interface: Configuration > Event > Basic Event > Motion Detection Select the channel to set the motion detection. Check the checkbox of the Enable Motion Detection to enable this function. © Hikvision...
  • Page 50 You can draw up to 8 motion detection areas on the same image.   You can click to clear all of the areas. (3) Move the slider to set the sensitivity of the detection.  Expert © Hikvision...
  • Page 51 The less the value is, the easier the alarm will be triggered. Set the Arming Schedule for Motion Detection. (1) Click tab to enter the arming schedule setting interface. © Hikvision...
  • Page 52 Figure 5-12 Arming Time Schedule (4) After setting the arming schedule, you can click a segment to display the segment arming settings interface to edit the segment record parameters (optional). Figure 5-13 Segment Arming Settings (5) Click to save the settings. © Hikvision...
  • Page 53 To send the Email when an event occurs, you need to refer to Section Configuring Email Settings to set the Email parameters. Upload to FTP/Memory/NAS  Capture the image when an alarm is triggered and upload the picture to a FTP server. © Hikvision...

  • Page 54: Configuring Video Tampering Alarm

    You can configure the positioning system to trigger the alarm actions when the lens is covered. Steps: 1. Enter the Video Tampering settings interface Configuration > Event > Basic Event > Video Tampering 2. Select the channel to set the video tampering alarm. © Hikvision...

  • Page 55: Configuring Alarm Input

    Configuration > Event > Basic Event > Alarm Input 2. Choose the alarm input No. and the Alarm Type. The alarm type can be NO (Normally Open) and NC (Normally Closed). 3. Edit the name in to set a name for the alarm input (optional). © Hikvision...
  • Page 56 6. You can also choose the PTZ linking for the alarm input. Check the relative checkbox and select the No. to enable Preset Calling, Patrol Calling or Pattern Calling. 7. You can copy your settings to other alarm inputs. 8. Click to save the settings. Figure 5-17 Linkage Method © Hikvision...

  • Page 57: Configuring Alarm Output

    Refer to Section 5.2.1 Configuring Motion Detection. Figure 5-18 Alarm Output Settings You can copy the settings to other alarm outputs. Click to save the settings. © Hikvision...

  • Page 58: Handling Exception

    2. Check the checkbox to set the actions taken for the Exception alarm. Refer to Section 5.2.1 Configuring Motion Detection. Figure 5-19 Exception Settings Click to save the settings. 5.3 Smart Event Configuration The functions vary depending on the models of positioning system. © Hikvision...

  • Page 59: Detecting Audio Exception

    4. Check the checkbox of Sudden Decrease of Sound Intensity Detection checkbox to enable the sudden drop detection. Sensitivity: Range [1-100], the smaller the value the more severe the sound change will trigger the detection. © Hikvision...

  • Page 60: Configuring Fire And Smoke Detection

    2. Enter the fire and smoke detection interface: Configuration > Event > Smart Event > Dynamic Fire and Smoke Detection Figure 5-21 Fire and Smoke Detection 3. Check the checkbox of Enable Fire and Smoke Detection to enable the fire and smoke detection function. © Hikvision...
  • Page 61 Step 3 in Section 5.2.1 Configuring Motion Detection. In the field of Other Linkage, you can check the checkbox to enable the alarm output (The alarm output number varies depending on device ability). Click to save the settings. © Hikvision...

  • Page 62: Configuring Fire Source Detection Shield

    5. Click Stop Drawing to finish drawing or click Clear All to clear all of the areas you set without saving them. 6. Set the value of Active Zoom Ratio on your demand, and then the shield will only appear when the zoom ratio is greater than the predefined value. © Hikvision...

  • Page 63: Configuring Smoke Detection Shield

    Smoke Detection Shield enables you to shield certain areas from being detected in smoke detection. The smoke detection shield function is supported by the optical lens only. Steps: 1. Enter the Smoke Detection Shield Setting interface: Configuration > Event > Smart Event > Smoke Detection Shield Figure 5-23 Smoke Detection Shield © Hikvision...

  • Page 64: Ship Detection

    When you enable this function and ship is detected, the alarm actions will be triggered. Steps: 1. Enter Configuration>Advanced Configuration>System>VCA Resource Type to select Ship Detection as VCA Resource Type. 2. Enter the ship detection interface: Configuration > Advanced Configuration > Smart Event > Ship Detection © Hikvision...
  • Page 65 15 s later. 5. Enter the device height in the textbox as the height of device above the water level. 6. Draw the ship detection area and the alarm lines. © Hikvision...

  • Page 66: Temperature Measurement

    Before You Start: Enter Configuration > Advanced Configuration > System > VCA Resource Type to select Temperature Measurement + Behavior Analysis as VCA Resource Type. 5.4.1 Temperature Measurement Configuration Steps: 1. Enter Configuration > Temperature Measurement > Basic Settings Configuration. © Hikvision...
  • Page 67  Temperature Range: Set the temperature range.  Emissivity: Set the emissivity of your target. Note: The emissivity of each object is different.  Distance (m): The straight-line distance between the target and the device. 3. Clcik Save to save the settings . © Hikvision...

  • Page 68: Temperature Measurement And Alarm

    Distance (m): The straight-line distance between the target and the device. Pre-Alarm Threshold: Set the pre-alarm temperature and the device sends pre-alarm when its rule temperature exceeds pre-alarm temperature. Alarm Threshold: Set the alarm temperature and the device sends alarm when its rule temperature exceeds alarm temperature. © Hikvision...
  • Page 69 Type: Select Point, Line, or Frame as rule type. Emissivity: Set the emissivity of your target. The emissivity of each object is different, you can refer to the Quick Start Guide Appendix for details. Distance (m): The straight-line distance between the target and the device. © Hikvision...
  • Page 70 E.g., select Alarm Rule as Average Temperature is Higher than, and set the Alarm Temperature to 50 ° C, and the device alarms when its average temperature is higher than 50 ° C. For Line Rule: a) Click to show the Alarm Rule setting interface. © Hikvision...
  • Page 71 E.g., select Alarm Rule as Temperature Difference is Higher than, and set the Alarm Temperature to 10 ° C, and the device alarms when the difference between the minimum temperature and the maximum temperature of the region is higher than 10 ° C. © Hikvision...
  • Page 72 Refer to Step 3 in Section 5.2.1 Configuring Motion Detection. In the field of Other Linkage, you can check the checkbox to enable the alarm output (The alarm output number varies depending on device ability). 4. Click to save the settings. © Hikvision...

  • Page 73: Chapter 6 Vca Configuration

    And if you tick the checkbox of display target info and rule on stream, the information will be added to the video stream, and the overlay will be displayed if you get live view or play back by the VS Player. 4. Set the Snapshot: © Hikvision...

  • Page 74: Advanced Configuration

    The greater the value is, the faster the target will be counted as the background. Minimum Target Size: Range [0-4], The system will filter out the object smaller than the minimum target size. © Hikvision...

  • Page 75: Behavior Analysis

    2. Configure the Zooming Ratio parameters: Set the appropriate tracking zooming ratio with the PTZ control panel. Click on to save the settings. The optical camera will track the target when the VCA rule is triggered which is configured on the thermal camera. © Hikvision...
  • Page 76 User Manual of Thermal Network Positioning system Figure 6-3 Zoom Ratio 3. Configure the Scene: Go to VCA > Scene Parameters At most 10 scenes can be added. Different rules and properties can be configured for each scene. Figure 6-4 Scene Parameters © Hikvision...
  • Page 77 For details, see6.4 Rule Configuration Demonstration. Enable rules: Check the Enable checkbox of each rule in the rule list to enable the rule. © Hikvision...
  • Page 78 Create multiple rules: You can create more rules by repeating the above steps.  Configure Arming schedule: Click the Arming Schedule tab. Select a rule from the rule list. Figure 6-6 Arming Schedule Click on the Edit button to edit the arming time segment. Figure 6-7 Schedule Time © Hikvision...

  • Page 79: Rule Configuration Demonstration

    4. Advanced Configuration: For details, see section 6.2 Advanced Configuration. Click to save the settings. 6.4 Rule Configuration Demonstration Purpose: This section provides detailed configuration steps for each rule. 6.4.1 Line Crossing Purpose: This function can be used for detecting people, vehicles and objects traversing a set virtual © Hikvision...
  • Page 80 Max. size filter. Configure the rule area: Click on the tool bar of the live view panel. Specify a point of the line by clicking the mouse on the live view image, and then specify the other one. © Hikvision...

  • Page 81: Intrusion

    Click the mouse on the live view image to specify a corner of the area. After you specify all the corners, right click the mouse to connect the first corner and the last corner, which means the polygonal area is drawn. © Hikvision...

  • Page 82: Region Entrance

    Right click the mouse to finish drawing. Configure the filtering size: for details, see step 3 in section 6.4.1 Line Crossing. Enable rules: Check the Enable checkbox of each rule in the rule list to enable the rule. Click to save the settings. © Hikvision...

  • Page 83: Region Exiting

    Figure 6-12 Draw Area Configure the filtering size: for details, see step 3 in section 6.4.1 Line Crossing. Enable rules: Check the Enable checkbox of each rule in the rule list to enable the rule. Click to save the settings. © Hikvision...

  • Page 84: Chapter 7 Positioning System Configuration

    Purpose: TCP/IP settings must be properly configured before you operate the positioning system over network. IPv4 and IPv6 are both supported. Steps: Enter TCP/IP settings interface: Configuration > Network > Basic Settings > TCP/IP Figure 7-1 TCP/IP Settings © Hikvision...
  • Page 85 The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. © Hikvision...
  • Page 86 (3) Enter the Port of DynDNS server. (4) Enter the User Name and Password registered on the DynDNS website. (5) Click to save the settings. Figure 7-4 DynDNS Settings IP Server:  Steps: (1) Enter the Server Address of the IP Server. © Hikvision...
  • Page 87 (2) In the Domain text field, enter the domain name obtained from the NO-IP website. (3) Enter the Port of NO-IP server. (4) Enter the User Name and Password registered on the NO-IP website. (5) Click to save the settings. Configuring PPPoE Settings Purpose: © Hikvision...
  • Page 88 If there is a router and you want to access the positioning system through Wide Area Network (WAN), you need to forward the 3 ports for the positioning system. Steps: 1. Enter the Port settings interface: Configuration > Network > Basic Settings > Port Figure 7-8 Port Settings © Hikvision...
  • Page 89 To port mapping with the default port numbers: Choose To port mapping with the customized port numbers: Choose And you can customize the value of the port number by yourself. Figure 7-9 Port Mapping Mode Click to save the settings. © Hikvision...

  • Page 90: Advanced Settings

    The SNMP version you select should be the same as that of the SNMP software. Steps: 1. Enter the SNMP settings interface: Configuration > Network > Advanced Settings > SNMP Figure 7-10 SNMP Settings © Hikvision...
  • Page 91 For your privacy and to better protect your system against security risks, we  strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a © Hikvision...
  • Page 92 Before you start: Please configure the DNS Server settings under Configuration> Network > Basic Settings > TCP/IP before using the Email function. Steps: 1. Enter the Email settings interface: Configuration> Network > Advanced Settings > Email © Hikvision...
  • Page 93 The password should be something of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. © Hikvision...
  • Page 94 Proper configuration of all passwords and other security settings is the responsibility  of the installer and/or end-user. © Hikvision...
  • Page 95 2) Click Create to create the certificate request, and fulfill the required information. 3) Download the certificate request and submit it to the trusted certificate authority for signature. 4) After receiving the signed valid certificate, import the certificate to the device. 5) Click OK to save the settings. © Hikvision...
  • Page 96 The valid DSCP value ranges from 0 to 63. The DSCP value is bigger, the priority is higher. 3. Click to save the settings.  Make sure that you enable the QoS function of your network device (such as a router).  It will ask for a reboot for the settings to take effect. © Hikvision...
  • Page 97 Proper configuration of all passwords and other security settings is the responsibility  of the installer and/or end-user. Steps: Connect the network camera to your PC directly with a network cable. Enter the 802.1X settings interface: Configuration > Network > Advanced Settings > 802.1X © Hikvision...

  • Page 98: Configuring Video And Audio Settings

    7.2 Configuring Video and Audio Settings 7.2.1 Configuring Video Settings Steps: 1. Enter the Video settings interface: Configuration > Video/Audio > Video Figure 7-22 Configure Video Settings 2. Select the Channel No. in the dropdown list you want to configure. © Hikvision...
  • Page 99 It refers to the smoothness of the stream. The higher value of the smoothing, the better fluency of the stream, though, the video quality may not be so satisfied. The lower value of the smoothing, the higher quality of the stream, though it may appear not fluent. 5. Click to save the settings. © Hikvision...

  • Page 100: Configuring Audio Settings

    There are two different ROI methods: Fixed Region and Dynamic Region. When Fixed Region is enabled, image quality of ROI area will be enhanced and image quality of other areas will be reduced. When Dynamic Region is enabled, image quality of tracking target will be enhanced. © Hikvision...
  • Page 101 ROI function varies depending on the models of positioning system. Steps: Enter the ROI settings interface: Configuration >Video/Audio > ROI Select the channel No. from the drop-down list. Figure 7-24 Region of Interest (1) Figure 7-25 Region of Interest (2) ROI for Fixed Region  Steps: © Hikvision...

  • Page 102: Ptz Configuration

    The functions vary depending on the models of positioning system.  7.3.1 Configuring Basic PTZ Parameters Purpose: You can configure the basic PTZ parameters, including proportional pan, preset freezing, preset speed, etc. 1. Enter the Basic PTZ Parameter Configuration interface: © Hikvision...
  • Page 103 Manual Control Speed: The positioning system provides 5 control speed modes: Compatible, Pedestrian, Non-motor Vehicle, Motor Vehicle and Auto. Select it from the dropdown list.  Keyboard Control Speed: Define the speed of PTZ control by a keyboard as Low, Medium or High. © Hikvision...

  • Page 104: Configuring Ptz Limits

    60 seconds, 300 seconds or 600 seconds before power-off. 3. Click to save the settings. 7.3.2 Configuring PTZ Limits Purpose: The positioning system can be programmed to move within the configurable PTZ limits (left/right, up/down). Steps: Enter the Limit configuration interface: Configuration > PTZ > Limit © Hikvision...

  • Page 105: Configuring Initial Position

    The initial position is the origin of PTZ coordinates. It can be the factory default initial position. You can also customize the initial position according to your own demand. Customize an Initial Position:  Steps: Enter the Initial Position Configuration interface: Configuration > PTZ > Initial Position © Hikvision...

  • Page 106: Configuring Park Actions

    3. Set the Park Time as the inactivity time of the positioning system before it starts the park actions. 4. Choose Action Type the from the dropdown list. Figure 7-30 Action Types 5. Select the Action Type ID from the dropdown list. 6. Click to save the settings. © Hikvision...

  • Page 107: Configuring Privacy Mask

    Privacy Mask List area; set the value of Active Zoom Ratio on your demand, and then the mask will only appear when the zoom ratio is greater than the predefined value. © Hikvision...

  • Page 108: Configuring Scheduled Tasks

    3. Set the Park Time. You can set the park time (a period of inactivity) before the positioning system starts the scheduled tasks. 4. Select the task type from the dropdown list. You can choose scan, preset, pattern and etc. © Hikvision...

  • Page 109: Clearing Ptz Configurations

    You can clear PTZ configurations in this interface, including all presets, patrols, privacy masks, PTZ limits, scheduled tasks and park actions. Pattern function varies depending on positioning system models. Steps: 1. Enter the Clearing Configuration interface: Configuration > PTZ > Clear Config © Hikvision...

  • Page 110: Prioritize Ptz

    3. Set the delay time (Range 2-200s). 4. Click to save the settings. 7.3.9 Position Settings Steps: 1. Enter the Position Settings interface: Configuration > PTZ > Position Settings. The actual interface may vary from model to model. © Hikvision...
  • Page 111 4. Set GPS settings. (1) Select Longitude-Latitude Mode as Manual. (2) Select longitude and latitude as East or West according to the actual position. (3) Enter the value of longitude and latitude in three textboxes. 5. Click to save the settings. © Hikvision...

  • Page 112: Configuring Linear Scan

    7. Optionally, you can click Clear to delete the saved scan area. 8. Click Save to save the settings and the Linear Scan Area shows Scan area saved. 9. Click Start Linear Scan and Stop Linear Scan to start and stop the saved linear scan. © Hikvision...

  • Page 113: Configuring Image Settings

    1. Enter the Display settings interface: Configuration > Image> Display Settings 2. Select the channel No. from the dropdown list. Figure 7-39 Display Settings 3. You can select the Scene in the dropdown list with different predefined image © Hikvision...
  • Page 114  Iris Priority: The value of iris needs to be adjusted manually. The shutter and gain values will be adjusted automatically according to the brightness of the environment. Figure 7-40 Manual Iris  Shutter Priority: © Hikvision...
  • Page 115 The positioning system focuses automatically at any time according to objects in the scene.  Semi-auto: The positioning system focuses automatically only once after panning, tilting and zooming.  Manual: In Manual mode, you need to use on the control panel to focus manually. © Hikvision...
  • Page 116 BLC (Back Light Compensation) If there’s a bright backlight, the subject in front of the backlight appears silhouetted or dark. Enabling BLC(back light compensation) function can correct the exposure of the subject. But the backlight environment is washed out to white. © Hikvision...
  • Page 117 You can select this mode when the positioning system is installed in outdoor environment.  Indoor You can select this mode when the positioning system is installed in indoor environment.  Fluorescent Lamp You can select this mode when there are fluorescent lamps installed near the positioning system. © Hikvision...
  • Page 118 You can set the Defog Mode to ON or OFF as you need. Figure 7-49 Defog Mode EIS (Electronic Image Stabilization)  You can set theEIS to ON or OFF as you need. Figure 7-50 Electronic Image Stabilization © Hikvision...
  • Page 119 You can set Zoom Limit value to limit the maximum value of zooming. The value can be selected from the list.  Local Output You can enable or disable the video output through the BNC interface on your demand. The functions vary depending on the models of positioning system. © Hikvision...
  • Page 120 Manual Background Correction  Fully cover the lens with an object (lens cover is recommended) and click the Manual Background Correction button, and then the positioning system adjusts the image according to the current environment. Manual Shutter Correction  © Hikvision...
  • Page 121 You can set the Capture Mode to OFF and 384*288@25fps.  Digital Zoom The digital zoom is available for the thermal sensor, there are x2 and X4 selectable. This function varies depending on the models of positioning system. © Hikvision...

  • Page 122: Configuring Osd Settings

    5. Select from the dropdown list to set the time format, date format, display mode, OSD size and Font color. 6. You can use the mouse to click and drag the text frame IPdome in the live view window to adjust the OSD position. © Hikvision...

  • Page 123: Configuring Text Overlay Settings

    There are up to 4 text overlays configurable. When the video resolution is 1080p, only one text overlay is supported. When PTZ direction, preset OSDs are displayed, the text overlay is disabled. Figure 7-54 Text Overlay Settings © Hikvision...

  • Page 124: Vca Rule Display

    2. Customize the color of line and frame for Normal, Pre-Alarm, and Alarm. 3. Click to save the settings. 7.4.5 Configuring DPC Settings DPC (Defective Pixel Correction) refers to the function that the camera can correct the defective pixels on the LCD which are not performing as expected. © Hikvision...

  • Page 125: Picture In Picture

    Enter Configuration > System > System Maintenance > VCA Resource Type to select Picture in Picture as VCA Resource Type. Purpose: The system plays the live view of thermal channel and optical channel at the same time. Steps: 1. Select the channel No. from the list. © Hikvision...

  • Page 126: Configuring System Settings

    Version, Encoding Version, Web Version, Plugin Version, Number of Channels, Number of HDDs, Number of Alarm Input and Number of Alarm Output are displayed. The information cannot be changed in this menu. It is the reference for maintenance or modification in future. © Hikvision...
  • Page 127 (DST) functions for setting the time. Time Synchronization consists of auto mode by Network Time Protocol (NTP) server and manual mode. Enter the Time Settings interface: Configuration > System > System Settings > Time Settings Figure 7-59 Time Settings  Configuring Time Synchronization by NTP Server Steps: © Hikvision...
  • Page 128 (3) Click to save the settings. You can also check the Sync with local time checkbox to synchronize the time of the positioning system with the time of your computer. Figure 7-61 Time Sync Manually © Hikvision...
  • Page 129 The RS-485 serial port is used to control the PTZ of the camera. The configuring of the PTZ parameters should be done before you control the PTZ unit. Steps: Enter RS-485 Port Setting interface: Configuration> Advanced Configuration> System > RS-485 © Hikvision...

  • Page 130: Maintenance

    Enter the Maintenance interface: Configuration > System > Maintenance > Upgrade & Maintenance: 2. Click to restore the default settings. Clicking restores all the parameters to default settings including the IP address and user information. Please use this button with caution. © Hikvision...
  • Page 131 The upgrading process will take 1 to 10 minutes. Please don't disconnect power of the positioning system during the process. The positioning system reboots automatically after upgrading. Figure 7-67 Remote Upgrade Log Searching Purpose: © Hikvision...
  • Page 132 The de-icing heater is only supported under POE+, 24VAC, or 12VDC power supply. 4. Select the power saving mode between manual and scheduled.  Power Saving Mode: Select power saving mode as manual, and you can turn on © Hikvision...
  • Page 133 Measurement and Behavior Analysis. To use Dynamic Fire Source Detection function, select Dynamic Fire Source Detection. To use Ship Detection function, select Ship Detection. Steps: 1. Enter the VCA Resource Type interface: Configuration > Advanced Configuration > System > VCA Resource Type Figure 7-70 VCA Information © Hikvision...

  • Page 134: Security

    Configuring IP Address Filter Purpose: With this function on, the camera allows certain IP addresses whether to log in or not. Steps: 1. Enter IP Address Filter interface: Configuration > System > Security > IP Address Filter © Hikvision...
  • Page 135 (2) Input the IP Adreess. Figure 7-72 Add an IP (3) Click OK to finish adding.  Modify an IP Address Steps: (1) Left-click an IP address from filter list and click Modify. (2) Modify the IP address in the text filed. © Hikvision...

  • Page 136: User Management

    7.5.4 User Management Enter the User Management interface: Configuration > System > User Management The admin user has access to create, modify or delete other accounts. Up to 32 user accounts can be created. © Hikvision...
  • Page 137 The level indicates the permissions you give to the user. You can define the user as Operator or User. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions for the new user. Click to finish the user addition. © Hikvision...
  • Page 138 1. Left-click to select the user from the list and click 2. Modify the User Name, Level or Password. 3. In the Basic Permission field and Camera Configuration field, you can check or uncheck the permissions. 4. Click to finish the user modification. © Hikvision...
  • Page 139 1. Left-click the user name you want to delete and click 2. Click on the pop-up dialogue box to delete the user. Online Users Enter the Online Users configuration interface: Configuration > System > User Management > Online Users © Hikvision...
  • Page 140 You can see the current users who are visiting the device through this interface. User information, such as user name, level, IP address, and operation time, is displayed in the User List. Click Refresh to refresh the list. © Hikvision...

  • Page 141: Appendix

    Figure A.1.1 Searching Online Devices Device can be searched and displayed in the list in 15 seconds after it went online; it will be removed from the list in 45 seconds after it went offline.  Search online devices manually © Hikvision...
  • Page 142 8 characters, including upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product. Proper configuration of all passwords and other security settings is the  responsibility of the installer and/or end-user. Figure A.1.2 Modify Network Parameters © Hikvision...

Table of Contents
