OPERATING CONTROLS AND PROCEDURES
To extend the left front stabilizer, push the top of the outrigger
extend/retract switch and the bottom of the left front outrigger
switch.
To retract the left front stabilizer, push the bottom of the
outrigger extend/retract switch and the bottom of the left front
outrigger switch.
Right Front Outrigger Switch
The right front outrigger switch (4) is located on the right side
of the controller. It is a three-position switch used to extend
or retract the right front stabilizer and extension cylinders. It
must be used in conjunction with the outrigger extend/retract
switch.
To extend the right front outrigger beam, push the top of the
outrigger extend/retract switch (1) and the top of the right
front outrigger switch.
To retract the right front outrigger beam, push the bottom of
the outrigger extend/retract switch and the top of the right
front outrigger switch.
To extend the right front stabilizer, push the top of the
outrigger extend/retract switch and the bottom of the right
front outrigger switch.
To retract the right front stabilizer, push the bottom of the
outrigger extend/retract switch and the bottom of the right
front outrigger switch.
Left Rear Outrigger Switch
The left rear outrigger switch (5) is located on the left side of
the controller. It is a three-position switch used to extend or
retract the left rear stabilizer and extension cylinders. It must
be used in conjunction with the outrigger extend/retract
switch.
3-40
To extend the left rear outrigger beam, push the top of the
outrigger extend/retract switch and the top of the left rear
outrigger switch.
To retract the left rear outrigger beam, push the bottom of the
outrigger extend/retract switch and the top of the left rear
outrigger switch.
To extend the left rear stabilizer, push the top of the outrigger
extend/retract switch and the bottom of the left rear outrigger
switch.
To retract the left rear stabilizer, push the bottom of the
outrigger extend/retract switch and the bottom of the left rear
outrigger switch.
Right Rear Outrigger Switch
The right rear outrigger switch (6) is located on the right side
of the controller. It is a three-position switch used to extend
or retract the right rear stabilizer and extension cylinders. It
must be used in conjunction with the outrigger extend/retract
switch.
To extend the right rear outrigger beam, push the top of the
outrigger extend/retract switch and the top of the right rear
outrigger switch.
To retract the right rear outrigger beam, push the bottom of
the outrigger extend/retract switch and the top of the right
rear outrigger switch.
To extend the right rear stabilizer, push the top of the
outrigger extend/retract switch and the bottom of the right
rear outrigger switch.
To retract the right rear stabilizer, push the bottom of the
outrigger extend/retract switch and the bottom of the right
rear outrigger switch.
