(11) must be applied (control knob pulled out). If the Trailing
Boom Trailer Emergency Brake Control is in the release
position (pushed in), the air brake system pressure will be
reduced and the Park and Trailing Boom Emergency Brake
will automatically reset to the brake applied (ON) position.
Swing Brake Engaged Indicator (Optional)
Swing brake engaged indicator (29) is located on the top left
side of the front console. The swing brake engaged indicator
(bottom of the indicator) illuminates red to warn the operator
that the swing brake release pressure is not enough to hold
the swing brake disengaged during trailing boom operation.
In addition to illuminating the indicator, a warning buzzer will
sound.
Suspension Inflation Control Switch
The suspension inflation control switch (34) is located on the
right side console. When positioned to the right to inflate, the
suspension air bags are inflated. When positioned to the left
to deflate, the suspension air bags are deflated.
NOTE: The suspension air bags should be inflated at all
times except when on outriggers or in a pick and
carry mode. Suspension air bags will deflate
automatically when superstructure key switch is
turned ON.
Suspension Deflated Indicator
The suspension deflated indicator (33) is located on the right
side console. The amber indicator illuminates when the air is
removed from the suspension air bags. It is controlled by four
pressure switches connected in series.
Diesel Exhaust Fluid (DEF) Level Gauge (ISX Engine)
This gauge (59), located on the right center of the front
control panel indicates the amount of fluid in the DEF tank.
Engine performance will be derated per the following
conditions:
• 3% derated during inducement
• 5% derated during the warning level of the fluid
• 10% derated when the fluid level is low.

Accessory Controls and Indicators

High Beam/Lamp Malfunction Indicator
The headlight high beam/lamp malfunction indicator (28) is
located at the top left of the center front console. The
indicator is a blue light that illuminates when the headlights
a r e o n h i g h b e a m o r a m b e r w h e n t h e r e i s a l a m p
malfunction.
GROVE
OPERATING CONTROLS AND PROCEDURES
Heater On/Off Switch
The heater on/off switch (7) is located on the right side
console. Press the right side of the switch to ON for heat.
Press the left side of the switch to turn the heater off.
Heater Control Switch
The heater control switch (52) is located on the right side
console. Push the switch to the right to (OPEN) the valve for
heat. Push the switch to the left to (CLOSE) the valve.
Heater/Air Conditioner Fan Switch
The heater/air conditioner fan switch (8) is located on the
right side console. The switch controls the speed which in
turn regulates the volume of air output of the heater and air
conditioner fan by positioning switch to: low (switch
positioned to left), medium (switch centered), and high
(switch positioned to right).
NOTE: Either air conditioner or heater switch must be
positioned to ON before the fan will become
operational.
Air Conditioner Switch (Optional)
The air conditioning switch (10) is located on the right side
console. The switch controls the operation of the optional air
conditioning system in conjunction with the fan switch. Press
the switch to the right to turn air conditioner on. Press the
switch to the left to turn the air conditioner off.
Windshield Wiper/Washer Switch
The windshield wiper/washer toggle switch (13) is located on
the lower right side of the front console. The switch is used
for removing moisture from the windshield.The switch has an
off and high position with six intermittent positions between
high and off. Pushing the switch up from the off position
energizes the wiper motor. Continue to push switch up for
each intermittent position and the high position. Push the
switch down to off to stop the motor and return the wiper
blade to the parked position.
Push the very top of the switch to activate the washer switch
to spray washer fluid on the windshield.
Headlights Switch
The headlights switch (21) is a three position switch located
on the bottom left side of the front console. The bottom
position is off. The center position will illuminate marker,
clearance and gauge lights. The top position will turn on the
headlights in addition to the marker, clearance and gauge
lights.
Beacon Light Switch (Optional)
The beacon light switch (19) is a two position, on-off switch
located on the left side of the front console that controls the
beacon light (42) on the top of the carrier cab.
