TMS800E13 OPERATOR MANUAL
Overload less than 25%
1 Sheaves Inspect all for damage.
Luffing
2 Mechanism/ Inspect for damage/leaks.
Cylinder
Collar-wear
3 Inspect all for damage.
pads
Overload from 25% to 49%
1 Sheaves Inspect all for damage.
Luffing
2 Mechanism/ Inspect for damage/leaks.
Cylinder
Collar-wear
3 Inspect all for damage.
pads
4 Collar-welds Inspect all for cracks.
Telescopic Inspect for bent or twisted sections. Check the boom
5
Sections for straightness.
Lift Cylinder
6 Inspect for bends or cracked welds.
Head Area
Turret-Base
7 Inspect for cracked welds.
Section
Locking Area
8 Inspect for elongated holes.
(Pin Booms)
9 Welds Inspect for cracks.
Inspect for cracked paint which could indicate twisted,
10 Paint
stretched, or compressed members.
GROVE
Published 02-06-2014, Control # 495-00
SAFETY INFORMATION
2
2-27
